INFINEON TLE4959CFXHAMA1 Differential Hall Speed Sensor
The TLE4959C FX is a RoHS-compliant, automotive-grade differential Hall speed sensor designed for transmission applications. It features high magnetic sensitivity, a large operating airgap, and dynamic self-calibration. Equipped with integrated capacitors for improved EMC robustness, it offers vibration suppression, high immunity against ESD, EMC, and mechanical stress, and is end-of-line programmable. Its configuration includes three-wire voltage interface, making it suitable for automotive environments. Ideal for transmission speed and direction sensing, it enhances vehicle control systems through reliable and precise magnetic sensing technology.
INFINEON TLE4959CFXHAMA1 Differential Hall Speed Sensor Specifications:
- Package: PG-SSO-3-52, three-pin RoHS compliant package
- Electrical interface: Three-wire voltage, pull-up resistor of 1.2kΩ for 5V applications
- Capacitors: 220 nF and 1.8 nF integrated on lead frame for EMC robustness
- Operating Voltage: 12V (recommended series resistor of 100Ω for protection)
- Magnetic sensing: Differential Hall sensor with high magnetic sensitivity
- Temperature Range: Automotive qualified range (exact range external to OCR data)
- Pulse durations: Forward direction pulse 38-52μs, backward direction 73-138μs depending on option
- Power-on pulse: 25.5-34.5μs, high-speed pulse: 25-52μs depending on configuration
- Input voltage: 5V for output and power, 12V recommended with resistor protection
- EMC immunity: Enhanced, with integrated capacitors for robustness against ESD and mechanical stress
- Programmability: End-of-line, adjustable transmission parameters
- Application: Suitable for automotive transmission speed and direction monitoring
- Certification: RoHS, AEC qualified
Buy the Infineon TLE4959C FX – Reliable Speed Sensor for Industrial Applications
Enhance your automotive transmission system with our high-performance differential Hall speed sensor. Designed for precision, durability, and ease of integration, this sensor ensures accurate detection of rotation speed and direction. Its robust construction offers high immunity against electromagnetic interference, mechanical stress, and voltage fluctuations. Ideal for automotive and industrial applications, it features programmable transmission parameters for customization. Purchase online today to benefit from quick delivery, technical support, and secure checkout, ensuring your project advances smoothly with reliable magnetic sensing technology.
Buy Infineon TLE4959C FX now and experience unmatched reliability and performance in transmission speed sensing technology.
Frequently Asked Questions
Where can I buy INFINEON TLE4959CFXHAMA1?
You can click on the BUY or RFQ button to purchase TLE4959CFXHAMA1 from an authorized INFINEON distributor.
How do I troubleshoot issues or seek technical support for part TLE4959CFXHAMA1?
You can download the TLE4959CFXHAMA1 datasheet or visit the INFINEON website for support.
Who is the manufacturer of TLE4959CFXHAMA1?
INFINEON
