ITT Cannon MS3112E12-3S Datasheet & Stock

The MS3112E12-3S from ITT Cannon is MIL-DTL-26482 series I box mount receptacle with 3 contacts. MIL-DTL-26482 series I connectors are available in various shell styles and shell plating with 48hr, 500hr salt spray exposure. The unmated connectors and protective covers meet 48hrs exposure to MIL-STD-1344 method 1001 per MIL-DTL-26482. It has a well-proven electrical capability and is designed to withstand extreme shock, exposure and vibration.




Intermateable, intermountable, interchangeable for MIL-C-26482, VG95328 connectors

Self levelling 3 point bayonet coupling assures fast and reliable mating / unmating

Precise alignment utilizing five keyways

High contact density, environmentally sealed & suitable for harsh environments

Operating temperature range from -55°C to +125°C

Insulation resistance is 5000Mohm at 25°C

500 mating cycles, operating voltage is 1000VAC

Resilient polychlorprene insulator & grommet

Aluminium alloy body material with olive drab chromate over cadmium plating

Copper alloy solder socket contacts with gold plating
