ITT CANNON 1208552001 Industrial Cable Plug
The 120-8552-001 is a versatile 3-position industrial cable plug with a rugged nitrile-butadiene rubber housing and machined copper alloy contacts with silver plating for reliable conductivity. Designed for harsh environments, it provides IP67 sealing for dust and water resistance, supported by tests for thermal endurance, vibration, and salt spray. Rated for 1200 VAC dielectric withstand voltage, this connector supports wire ranges of 0.75-1.5 mm², with a contact retention force of 35N and a contact resistance of 10 milliohms. Capable of up to 50 mating cycles, it operates effectively from -40°C to 105°C in industrial settings.
ITT CANNON 1208552001 Industrial Cable Plug Specifications:
- Housing Material: Nitrile-butadiene rubber
- Contacts: Copper alloy, machined, silver plated
- Contact Resistance: 10 milliohms max
- Insulation Resistance: 100 megaohms min
- Dielectric Withstand Voltage: 1200 VAC at sea level
- Wire Range: 0.75-1.5 mm² (AWG 18-14)
- Sealing: IP67 dust and waterproof
- Operating Temperature: -40°C to 105°C
- Contact Retention Force: 35N minimum
- Durability: 50 cycles of mating and unmating
- Temperature Rating: -40°C to +105°C
- Dimensions: See manufacturer datasheet for detailed specs
Buy the Reliable Industrial Connectors for Harsh Environments
Order the 120-8552-001 industrial cable plug online today for durable performance in demanding environments. Featuring robust nitrile-butadiene rubber housing and high-quality copper contacts, this connector ensures IP67 sealing, excellent electrical performance, and long-term durability. Perfect for industrial automation, machinery, and outdoor equipment, it supports wire ranges of 0.75 to 1.5 mm², withstands up to 50 mating cycles, and operates from -40°C to 105°C. Enhance your project reliability with secure, water-tight connections available now through our online platform.
Buy ITT Cannon 1208552001 now and experience unmatched reliability and performance for industrial applications involving harsh conditions.
Frequently Asked Questions
Where can I buy ITT CANNON 1208552001?
You can click on the BUY or RFQ button to purchase 1208552001 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part 1208552001?
You can download the 1208552001 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of 1208552001?
ITT CANNON
