ITT CANNON 1320150130 8 Way Receptacle Connector
The ITT CANNON 132015-0130 is a robust 8-way circular connector designed for demanding industrial environments. This black receptacle connector offers a secure connection with a current rating up to 13A and an operating voltage up to 250V ac rms. It is designed to withstand harsh conditions, including extreme temperatures, vibration, and fluid exposure, with environmental sealing up to IP69K when used with end caps. The connector's construction utilizes thermoplastic housing, silicone rubber gaskets, and brass or copper alloy contacts with tin, gold, or silver plating, ensuring long-term reliability and performance.
ITT CANNON 1320150130 8 Way Receptacle Connector Specifications:
- Series: CTC
- Style: Receptacle
- Color: black
- Number of Contacts: 8
- Current Rating: Up to 13A, up to 16A with high conductivity contacts
- Operation Voltage: Up to 250V ac rms
- Wire Range: 24-16 AWG (0.20 to 1.50 mm²)
- Operating Temperature: -55°C to +105°C (-67°F to +221°F)
- Durability: 200 cycles (T2P) and up to 500 cycles (T3P)
- Single Contact Retention Force: > 67N
- Single Contact Inserting Force: < 50N
- Connector Mating Withdrawal Force: <130N
- Latch Retention Force: >125N
- Environmental Sealing: Up to IP69K with end caps
- Flammability: UL 94 V-0
- Dielectric Voltage: 1550 V ac for 60 seconds
- Thermal Shock: -55°C to +125°C (-67°F to +257°F), 5 cycles
- Physical Shock: 50g s peak, 3 axes, 11millisecond duration half-sine pulse, no loss of continuity >1µsec
- Fluid Resistance: No damage when exposed to most industrial fluids
- Vibration: 10g’s peak, 10-500 Hz, 9 hours, no loss of continuity >1µsec
- Salt Spray: 48 hours
- Temperature Endurance: 1000 hours at 125°C (+257°F); Insulation resistance >100MΩ
- Humidity: Steady state RH 90-95%, 40°C (+104°F), 504 hours; Insulation resistance > 100MΩ
- Submersion: No loss of electrical performance in mated condition, wired, submerged 1 meter for 30 minutes
- Moisture Resistance: 10 Cycles; Insulation resistance > 100MΩ
- Housing End Cap Material: Thermoplastic
- Seal Gasket Material: Silicone rubber
- Interface Gasket Material: Silicone rubber
- Contacts Material: Brass or copper alloy & stainless steel. Tin, gold, silver plated
