ITT CANNON 1929000003 High Power Connector
The product is a high-power electrical connector designed for harsh environments, featuring a rugged construction with silver plated copper contacts. Suitable for power and signal applications, it offers IP67/IP69K sealing, high vibration resistance, and a temperature range of -40°C to 125°C. The connector supports up to 245A current, incorporates a durable PBT GF housing with optional sealing parts, and is compatible with various cable sizes. It is ideal for transportation, industrial, and military applications requiring reliable, sealed, and high-current connections.
ITT CANNON 1929000003 High Power Connector Specifications:
- Operating Voltage: 48 VDC
- Operating Current: up to 245A
- Contact Resistance: max 0.4 mΩ
- Voltage Proof: 1000 VAC, 60 seconds
- Insulation Resistance: min 10 MO
- Durability: 50 mating cycles
- Coupling Torque: max 2 Nm
- Temperature Range: -40°C to 125°C
- Sealing: IP67/IP69K
- Vibration Resistance: Sine, 100-300 m/s², 3 x 100h
- Materials: Housing - PBT GF, Contacts - Copper Alloy Sn or Au plated
- Fluid Compatibility: Brake fluid, ATF, fuel
- Housing Parts: PBT GF, Sealing Parts: FKM or HNBR
- Coupling Nut: PA 66 GF
Buy the ITT APD-245 High Power Reliable Connector for Harsh Environments
Order the high-power sealed connector today to ensure reliable, high-current connections in harsh environments. Designed for transportation, industrial, and military use, this connector features IP67/IP69K sealing, silver plated copper contacts supporting up to 245A, and a durable housing. Easy to install with compatible sealings and reliable performance at -40°C to 125°C temperatures. Perfect for demanding applications requiring vibration resistance, water ingress protection, and long-term durability. Buy online now to secure your solution for rugged electrical connections.
Get ITT APD-245 high-power connector today—built for reliability, high current capacity, and sealed performance in demanding industrial applications.
Frequently Asked Questions
Where can I buy ITT CANNON 1929000003?
You can click on the BUY or RFQ button to purchase 1929000003 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part 1929000003?
You can download the 1929000003 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of 1929000003?
ITT CANNON
