ITT CANNON 3308672001 Sealed Circular Connector
The Sure-Seal series high-reliability circular connector is designed for automotive, motorcycle, marine, and off-road applications. Featuring a robust one-piece resilient body with multiple moisture seals, it ensures protection against contaminants, shock, vibration, and extreme temperature variations. It’s easy to assemble using only the body and contacts, meeting Department of Transportation safety standards. Suitable for various environmental conditions, it offers IP67 sealing, is field serviceable, and polarized to prevent mis-mating. It reliably operates across -40°F to +221°F, making it ideal for demanding sectors like defense, aerospace, industrial, and consumer electronics.
ITT CANNON 3308672001 Sealed Circular Connector Specifications:
- Material: Nitrile-Butadien rubber insulator, copper alloy contacts with tin or silver plating
- Operating Voltage: 48 VDC
- Current Rating: 2-10 contacts, up to 17 A
- Contact Resistance: Max. 10 Milliohms
- Dielectric Withstanding Voltage: 1200 VAC at sea level
- Insulation Resistance: Min. 100 Megaohms
- Wire Range: 0.5-1.5 mm² (AWG 20-16 for smaller currents, AWG 18-14 for higher currents)
- Sealing Range: 1,8-2,8 mm
- Environmental Resistance: IP67, salt spray 100 hours, vibration 10-55 Hz, shock, oils, ozone resistant
- Temperature Range: -40°C to +105°C (-40°F to +221°F)
- Durability: 50-100 mating cycles
- Application Standards: Meets DIN 400 50, IEC 60529, SAE J1127
- Physical: Polarized positive design, stepped plane for correct mating
- Dimensions: Refer to manufacturer specifications in mm
Buy the ITT Series Sure-Seal Circular Connector: 3308672001
Purchase the ITT Sure-Seal circular connector now to ensure reliable, sealed connections for demanding automotive, marine, and industrial applications. Its IP67 rating protects against dust, water, and harsh conditions, making it perfect for environments exposed to vibration, temperature extremes, and moisture. Easy to assemble and field serviceable, this connector features polarized design to prevent mis-mating, complying with safety standards. Whether for manufacturing, maintenance, or custom applications, buy online today and benefit from high quality, durability, and proven performance in critical environments.
Get ITT Sure-Seal 3308672001 today—engineered for automotive, marine, and industrial environments with IP67 sealing and high durability.
Frequently Asked Questions
Where can I buy ITT CANNON 3308672001?
You can click on the BUY or RFQ button to purchase 3308672001 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part 3308672001?
You can download the 3308672001 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of 3308672001?
ITT CANNON
