ITT CANNON 3518697005 High Power Connector
The high power snap-in receptacle is designed for robust electrical connections in harsh environments, including automotive, industrial, and aerospace applications. It features a durable copper alloy contact system, silver plating for enhanced conductivity, and a reliable sealing system to meet IP67 and IP69K standards. The connector incorporates visual color coding for easy identification, and is supplied with accessories like hex nuts and cable seals. Its compact design ensures efficient power transfer up to 245A, while maintaining high vibration and mechanical stability across a wide temperature range from -40°C up to 125°C. Suitable for quick snap-in mating, it offers excellent long-term performance in demanding settings.
ITT CANNON 3518697005 High Power Connector Specifications:
- Contact Material: Copper Alloy, silver plated
- Electrical Current: Up to 245A
- Operating Voltage: 48 VDC
- Sealing Standard: IP67 and IP69K (DIN EN 60529)
- Temperature Range: -40°C to +125°C
- Vibration Resistance: High, suitable for harsh environments
- Durability: 50 mating cycles
- Mechanical Rating: Max coupling torque 2 Nm
- Housing: PBT GF or similar high-performance thermoplastics
- Wall Thickness Compatibility: Min 1.0 mm, Max 4 mm, with option for up to 5 mm with special jam nut
- Accessories: Hex nuts, cable seals, flange and panel mounting options
- Color Coding: Blue, Red, Black for easy identification
Buy the ITT Series High Power Snap-In: 3518697005
Purchase the high power snap-in connector online today and ensure your electrical system's reliability under demanding conditions. With a robust copper alloy contact system, silver plating for maximum conductivity, and a sealed IP67/IP69K design, this connector is ideal for automotive, industrial, and aerospace applications. Its compact form factor combined with a simple snap-in mechanism allows quick mating and disconnection, reducing installation time. Trust ITT's proven quality and order now to benefit from durable, vibration-resistant performance that withstands extreme temperatures from -40°C to 125°C for long-lasting operational excellence.
Buy ITT high power snap-in connector now and experience reliable, high-current transfer with IP67/IP69K sealing for industrial and automotive applications.
