ITT CANNON CA3108R181SF80F0 Circular Connector
The CA3108R18-1SF80F0 from ITT Cannon is a MIL-DTL-5015 compatible right-angle circular connector with a threaded coupling, featuring 10 contacts and a compact aluminum alloy shell. Designed for high durability, it withstands environments with temperature ranges from -55°C to +125°C, providing high sealing performance, IP67/IP68/IP69k ratings, and resistance to salt spray for 500 hours. The connector supports 500 mating cycles, has a contact resistance of less than 35N retention force, and handles voltages up to 50VAC. Its corrosion-resistant olive drab chromate finish and neoprene insulator ensure reliable, long-lasting connections in industrial applications.
ITT CANNON CA3108R181SF80F0 Circular Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate coating over cadmium plating
- Contact Arrangement: 18-1 with 10 contacts size 16, crimp type, silver plated
- Operating Voltage: Up to 50VAC; Insulation Resistance: >1000 MΩ as per VG95319 standards
- Temperature Range: -55°C to +125°C, suitable for harsh environments
- Salt Spray Resistance: 500 hours, Mating Cycles: 500 times, Contact Retention: 35N
- Coupling Torque: Closing 8 Nm max, Opening 0.58 Nm min; Seating Force: 1.0N per contact
- Sealing: IP67/IP68/IP69k Levels, with ingress protection in challenging conditions
- Dimensions & Gasket Material: Neoprene insulator, quick-mate threaded coupling for secure locking
Buy the ITT Circular CA3108R18-1SF80F0 – Reliable MIL-DTL-5015 Connector for Industrial Applications
Purchase the ITT Cannon Circular Connector now for dependable performance in harsh industrial settings. Designed with a threaded coupling, high IP ratings, and corrosion resistance, it provides secure and reliable connections up to 500 mating cycles. Ideal for applications demanding environmental sealing, temperature resilience, and mechanical durability, this connector is perfect for automation, military, and industrial equipment. Order online today to ensure your projects benefit from premium quality, quick delivery, and long-lasting operation in demanding environments.
Get ITT Cannon CA3108R18-1SF80F0 today—built for high durability and reliable performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy ITT CANNON CA3108R181SF80F0?
You can click on the BUY or RFQ button to purchase CA3108R181SF80F0 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part CA3108R181SF80F0?
You can download the CA3108R181SF80F0 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of CA3108R181SF80F0?
ITT CANNON
