ITT CANNON DAMM15PD High-Reliability D-Sub Connector
The D*M Series D-Sub high-reliability connector features 15 contacts for industrial and electronic applications. With a gold over nickel contact finish, it supports wire gauges from 20 to 28 AWG and is rated for up to 7.5 A. The connector withstands dielectric voltages of 1000 VAC at sea level and operates in temperatures ranging from -55°C to +150°C. Its shell is made of steel with a yellow chromate zinc finish, ensuring durability and corrosion resistance. Designed for right-angled PCB mounting, it is ideal for demanding electronic interconnections requiring reliable performance and high durability.
ITT CANNON DAMM15PD High-Reliability D-Sub Connector Specifications:
- Number of contacts: 15 contacts, size 20
- Wire Gauge Range: AWG 20-28
- Mating Cycles: 500
- Dielectric Withstanding Voltage: 1000 VAC at sea level
- Current Rating: 7.5 A maximum
- Contact Resistance: 7.5 milli Ohm max
- Operating Temperature: -55°C to +150°C
- Shell Material: Steel with yellow chromate over zinc finish
- Insulator Material: Thermoplastic, UL 94V-0 rated
- Insulator Color: Black
- Contact Type: Right-angled PCB Pin
- Contact Material: Copper alloy
- Contact Finish: Gold over nickel (Performance Class 2)
- Hardware: 120 inch (3.05 mm) through hole
- Salt Spray Resistance: 48 hours (96 hours for stainless steel)
- Gender: Pin
Buy the Cannon Series D*M D-Sub: DAMM15PD
Order the Cannon DAMM15PD high-reliability D-Sub connector online today and ensure robust, long-lasting connections for your electronic and industrial projects. Featuring 15 contacts with gold-over-nickel finish, it supports wire ranges from 20 to 28 AWG and handles currents up to 7.5 A. Its steel shell with yellow chromate coating provides excellent corrosion resistance, and the high dielectric withstand voltage of 1000 VAC ensures safety. Perfect for PCB mounting, this durable connector guarantees reliable performance in harsh environments and demanding applications.
Buy Cannon DAMM15PD now and experience unmatched reliability and performance with durable steel shell and gold-plated contacts for demanding electronic applications.
Frequently Asked Questions
Where can I buy ITT CANNON DAMM15PD?
You can click on the BUY or RFQ button to purchase DAMM15PD from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DAMM15PD?
You can download the DAMM15PD datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DAMM15PD?
ITT CANNON
