ITT CANNON DAMM3W3P Shielded D-Sub Connector
The Combo D Series are adaptable D-Subminiature connectors designed for space efficiency and superior shielding in various industries. These shielded I/O interconnects feature customizable layouts, combining multiple connection types within a single fully shielded system. They support high voltage up to 2800 VAC and operate across a broad temperature range of -55°C to 125°C. Constructed with steel shells finished in yellow chromate over zinc for durability, they include thermoplastic insulators rated UL 94V-0. Suitable for communications, aerospace, industrial automation, and defense applications, these connectors improve EMI/RFI shielding while reducing I/O complexity.
ITT CANNON DAMM3W3P Shielded D-Sub Connector Specifications:
- Shell Material: steel with yellow chromate over zinc finish
- Insulator Material: thermoplastic UL 94V-0
- Contact Arrangement: 3W3 (3 empty in 8 cavities)
- Wire Gauge Range: AWG 8-26
- Dielectric Withstanding Voltage: 500 VAC at sea level
- Current Rating: Signal contacts up to 7.5 A
- Operating Temperature: -55°C to +150°C
- Mounting Method: 3.05 mm (120 inch) through hole
- Supports high voltages up to 2800 VAC
- Flammability Rating: UL94V-0
- Compatible with PC boards up to 3.2 mm thick
- Suitable for aerospace, industrial, and communication sectors
Buy the Cannon DAMM3W3P – Reliable Shielded D-Sub Connectors for Industrial Applications
Purchase the Cannon DAMM3W3P shielded D-Sub connector online today and upgrade your industrial, aerospace, or communication systems. Designed for durability and high performance, these connectors feature a steel shell finished in yellow chromate over zinc for corrosion resistance, thermoplastic insulators rated UL 94V-0, and support high voltages up to 2800 VAC. With a wide operating temperature range, they provide excellent EMI/RFI shielding to ensure signal integrity in critical applications. Easily mounted with a 3.05 mm through hole, they are ideal for space-constrained, high-reliability environments requiring robust, customizable interconnect solutions.
Order your Cannon DAMM3W3P series high-performance shielded D-Sub connectors today and ensure reliable connections in demanding industrial environments.
Frequently Asked Questions
Where can I buy ITT CANNON DAMM3W3P?
You can click on the BUY or RFQ button to purchase DAMM3W3P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DAMM3W3P?
You can download the DAMM3W3P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DAMM3W3P?
ITT CANNON
