ITT-Cannon DAU15SA197FO D-Sub Connector
The Cannon DAU-15S-A197-FO is a low-cost, high-quality crimp connector designed for versatile electronic and electrical applications. This socket-style D-Sub connector features 15 contacts with a gold-over-nickel finish, ensuring reliable connectivity and corrosion resistance. With a current rating of 5 A and dielectric withstand voltage of 1000 VAC at sea level, it supports robust performance in demanding environments. Made from steel with a tin/nickel finish, its thermoplastic insulator withstands temperatures from -55°C to +125°C. Suitable for through-hole mounting, it offers durability through 50, 200, or 500 mating cycles.
ITT-Cannon DAU15SA197FO D-Sub Connector Specifications:
- Wire Gauge Range: AWG 18-30
- Mating Cycles: 50, 200, 500
- Dielectric Withstanding Voltage: 1000 VAC at sea level
- Current Rating: 5 Amax
- Contact Resistance: 15 milli Ohm max
- Operating Temperature: -55°C to +125°C
- Salt Spray Test: 20 hours
- Shell Material: Steel
- Shell Finish: Tin/Nickel
- Insulator Material: Glass-filled Thermoplastic, UL 94V-0
- Insulator Color: Black
- Contact Arrangement: 15 contacts, size 20
- Gender: Socket
- Contact Material: Copper alloy
- Contact Finish: Gold over nickel
- Contact Type: stamped
- Contact Termination: Crimp
- Mounting Method: Through Hole, 120" (3.05 mm)
Buy the Buy Cannon DAU-15S-A197-FO Part Number DAU-15S-A197-FO Online
Secure your electrical and electronic projects with the Cannon DAU-15S-A197-FO D-Sub connector, offering 15 gold-over-nickel plated contacts, a robust steel shell, and thermoplastic insulation. Designed for through-hole mounting, it supports 50, 200, or 500 mating cycles, with a 5 A current rating, dielectric withstand voltage of 1000 VAC, and operating temperature from -55°C to +125°C. Ideal for industrial, automation, and electronics applications, this connector ensures reliable, corrosion-resistant connections in demanding environments and high-performance settings.
Get Cannon DAU-15S-A197-FO today—built for reliable connections and long-lasting durability in demanding environments.
