ITT CANNON DB25PK87 D-Sub Connector
The DB25PK87 is a 25-position solder D-sub plug with copper contacts finished with gold flash, designed for high reliability and flexible solder terminations. It features a 5A current rating at 1250V, operates across a temperature range of -55°C to +125°C, and is constructed with a steel shell with tin finish. The connector provides excellent durability with 50 mating cycles, UL94V-0 flammability rating, and can be used in various commercial industrial applications. Its robust design ensures consistent electrical performance and field serviceability without specialized tools.
ITT CANNON DB25PK87 D-Sub Connector Specifications:
- Contacts: Copper alloy with gold flash finish
- Number of contacts: 25, size 20
- Current rating: 5A at 1250V
- Operating temperature: -55°C to +125°C
- Dielectric Withstanding Voltage: 1200 VAC at sea level
- Shell Material: Steel with tin finish
- Insulator Material: Thermoplastic UL 94V-0
- Insulator Color: Black
- Mating Cycles: 50
- Gender: Pin
- Mounting Method: Through hole 3.05mm (120 inch)
- Contact Termination: Solder pot
- Salt Spray Test: 20 hours
Buy the Cannon Series D Sub DB25PK87: 25-Position Solder Plug
Experience the reliable performance of the Cannon D-Sub Connector DB25PK87, a 25-position solder plug featuring gold flash contacts and a robust steel shell. Designed for applications requiring high electrical performance and durability, it supports up to 5A at 1250V with a wide operating temperature range from -55°C to +125°C. Suitable for various industrial and commercial uses, this connector ensures easy field repairs and long-lasting connections. Buy online now for fast, dependable delivery to meet your project needs.
Get Cannon DB25PK87 today—built for durability and reliable solder connections in industrial and commercial environments.
