ITT CANNON DBM17W2SA197 Shielded D Subminiature Connector
The Combo D Series connectors are versatile, shielded D subminiature interfaces designed for space-constrained applications requiring reliable EMI/RFI protection. They support a wide wire gauge range of AWG 8-26 and feature a 17W2 contact arrangement with 15 contacts size 20 and 2 empty cavities size 8. Crafted from durable steel with a gold flash finish, these socket-style solder pot contacts are rated for up to 7.5A. They withstand voltages up to 500 VAC at sea level and operate from -55°C to +125°C, making them suitable for diverse high-performance industries including aerospace, defense, and industrial automation.
ITT CANNON DBM17W2SA197 Shielded D Subminiature Connector Specifications:
- Wire Gauge Range: AWG 8-26
- Mating Cycles: 50
- Contact Arrangement: 17W2 (15 contacts size 20, 2 empty size 8 cavities)
- Dielectric Withstanding Voltage: 500 VAC at sea level
- Current Rating Signal Contacts: 7.5A max
- Contact Resistance: 10 milli Ohm max
- Operating Temperature: -55°C to +125°C
- Shell Material: Steel
- Shell Finish: Pure tin over nickel
- Insulator Material: Thermoplastic, UL 94V-0
- Contact Finish: Gold flash (Performance Class 3)
- Mounting Method: 120" (3,05mm) Through Hole
Buy the Cannon Series COMBO D D-Sub Connector: DBM17W2SA197
Purchase the Shielded D Subminiature Connector from Cannon online today and enjoy a robust, high-quality interconnect solution that supports AWG 8-26 wire gauges. Designed for demanding environments, it offers excellent EMI/RFI shielding, withstands voltages up to 500 VAC, and operates reliably from -55°C to +125°C. This connector features a durable steel shell with a gold flash finish, ensuring longevity and excellent electrical contact. Ideal for aerospace, defense, industrial automation, and communication systems, it provides a secure and versatile connection in space-sensitive designs.
Buy Cannon DBM17W2SA197 now and experience unmatched reliability and high-performance shielding for critical industrial and aerospace applications.
Frequently Asked Questions
Where can I buy ITT CANNON DBM17W2SA197?
You can click on the BUY or RFQ button to purchase DBM17W2SA197 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DBM17W2SA197?
You can download the DBM17W2SA197 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DBM17W2SA197?
ITT CANNON
