ITT CANNON DBM21W1SA197 Combination Connectors
The Combo D D*MM series consists of combination D Subminiature Connectors that offer the advantages of a standard shielded I/O interconnect with the flexibility of customized designs for various applications. These connectors are ideal for space-conscious setups requiring enhanced shielding and reduced EMI/RFI leakage by integrating multiple interconnect types into a fully shielded system. Features include standard and European footprints, pre-installed high-quality coaxial or high-power contacts, options for vertical standoffs or 90° brackets, and compatibility with both straight and 90° PCB mounting. They support PCBs up to 3.2mm thick and variants with boardlocks or screw locks (such as #4-40 or M3). The connectors can handle high voltages up to 2800 VAC, have a UL94V-0 flammability rating, and operate across a temperature range of -55°C to 125°C. Suitable for a wide range of industries including communications, networking, computer peripherals, automotive, mining, oil & gas, defense, aerospace, sensing, and industrial applications.
ITT CANNON DBM21W1SA197 Combination Connectors Specifications:
- Flammability: UL 94V-0
- Temperature Rating: -55°C to 125°C
- Signal Contact Current Rating: 7.5 A
- Signal Contact Resistance: 55 millivolt max. at 7.5 A
- Dielectric Withstanding Voltage: 1250 VAC at Sea Level
- Coaxial Current Rating: 5A
- Coaxial Impedance: Less than 1.40 + .03F for F up to 1GHz
- Coaxial VSWR: Less than 1.40 + .03F for F up to 1GHz
- Coaxial Insertion Loss: 0.2dB at 1 GHz
- High Power Current Rating: Up to 40 A
- High Voltage: 2800 VAC at Sea Level
- Materials and Finishes: Copper Alloy, Tin-Nickel, Gold over Nickel, Teflon insulator
- Operating Temperature Range: -55°C to 125°C
Buy the Buy Industry-Standard Shielded Combination Connectors Part Number DBM21W1SA197 Online
Discover the high-performance Combo D series combination connectors made for demanding industrial, aerospace, and communication applications. Featuring high voltage up to 2800 VAC, PCB compatibility up to 3.2mm thickness, and options for European or standard footprints, these fully shielded connectors reduce EMI/RFI leakage and provide flexible mounting with vertical or 90° brackets. Constructed from durable materials with high-quality finishes, they operate across wide temperature ranges from -55°C to 125°C. Whether for high power, coaxial, or high voltage applications, order online now to secure dependable, industry-standard interconnect solutions for your critical projects.
Order your industry-grade Combo D series high-voltage, shielded connectors with PCB support today and enhance your industrial, aerospace, or telecom projects with reliable, fully shielded interconnects.
Frequently Asked Questions
Where can I buy ITT CANNON DBM21W1SA197?
You can click on the BUY or RFQ button to purchase DBM21W1SA197 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DBM21W1SA197?
You can download the DBM21W1SA197 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DBM21W1SA197?
ITT CANNON
