ITT CANNON DBMA25P D-Sub Connector
The DBMA25P is a reliable 25-position D-sub connector designed for high-performance electronic systems. Featuring gold-over-nickel plated copper alloy contacts and a tin-plated steel shell, it ensures excellent electrical conductivity and corrosion resistance. The connector's black thermoplastic insulator rated UL94V-0 provides durability and safety. Compatible with wire gauges 20-28 AWG, it supports crimp contact termination and offers a maximum current of 7.5A. With a dielectric withstand voltage of 1000VAC and an operating temperature from -55°C to +125°C, it is ideal for computer and peripheral uses requiring high reliability and secure connections.
ITT CANNON DBMA25P D-Sub Connector Specifications:
- Contact Arrangement: 25 contacts size 20
- Wire Gauge Range: AWG 20-28 (Standard), AWG 22-28 (High Density)
- Current Rating: 7.5 A max
- Contact Resistance: 10 milli Ohm max
- Dielectric Withstanding Voltage: 1000 VAC at sea level
- Operating Temperature: -55°C to +125°C
- Shell Material: Steel
- Shell Finish: Tin
- Insulator Material: Thermoplastic, UL 94V-0 rated
- Contact Material: Copper alloy
- Contact Finish: Gold over nickel
- Hardware: 120" (3.05mm) through hole
- Mating Cycles: 200
Buy the Cannon DBMA25P – Reliable D-Sub Connector for Industrial Applications
Purchase the Cannon DBMA25P series D-Sub connector online today and experience dependable electrical connections for your computer, communication, and industrial applications. Featuring gold-over-nickel contacts and a robust steel shell, this connector offers excellent corrosion resistance, high reliability, and secure crimp termination. Suitable for wire gauges 20-28 AWG, with a current rating of up to 7.5A and dielectric voltage of 1000VAC, it is perfect for demanding environments. Get this high-quality connector online and enhance your project’s performance and durability.
Order your Cannon Series DBMA25P today and secure high-quality, durable connections for your electronic projects.
Frequently Asked Questions
Where can I buy ITT CANNON DBMA25P?
You can click on the BUY or RFQ button to purchase DBMA25P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DBMA25P?
You can download the DBMA25P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DBMA25P?
ITT CANNON
