ITT CANNON DBMM25PD High-Reliability D-Sub Connector
The D*M high-reliability D-Sub connector features 25 contacts for robust signal transmission in demanding environments, suitable for industrial and electronic applications. Constructed with steel shell finished in yellow chromate over zinc for corrosion resistance, it supports wire gauges from AWG 20 to 28 and offers 500 mating cycles. The thermoplastic insulator is UL 94V-0 rated, in black, ensuring durability. It has a contact resistance of max 7.5 milli Ohm, a dielectric voltage withstand of 1000 VAC, and can operate within -55°C to +150°C. Its right-angled PCB pin design ensures reliable mounting and electrical connection.
ITT CANNON DBMM25PD High-Reliability D-Sub Connector Specifications:
- Wire Gauge Range: AWG 20-28
- Mating Cycles: 500
- Contact Arrangement: 25 contacts, size 20
- Dielectric Withstanding Voltage: 1000 VAC at sea level
- Current Rating: 7.5 A max
- Contact Resistance: max 7.5 milli Ohm
- Operating Temperature: -55°C to +150°C
- Shell Material: Steel with yellow chromate over zinc finish
- Insulator Material: Thermoplastic, UL 94V-0 rated
- Insulator Color: Black
- Contact Type: Right-angled PCB
- Contact Material: Copper alloy
- Contact Finish: Gold over nickel
- Hardware: 120" (3.05 mm) through hole
- Salt Spray Test: 48 hours (96 hours for stainless steel)
Buy the Cannon Series D M D-Sub: DBMM25PD
Purchase the high-reliability D-Sub connector featuring 25 contacts from Cannon online today. Designed for durability with steel shell finished in yellow chromate over zinc, it supports wire gauges from AWG 20 to 28. This connector offers 500 mating cycles, a current rating of 7.5 A, and withstands operating temperatures from -55°C to +150°C. Its thermoplastic insulator with UL 94V-0 rating, gold-over-nickel contacts, and right-angled PCB pin design ensure reliable, long-lasting electrical connections for industrial and electronic applications.
Order your Cannon Series D M DBMM25PD high-reliability connector today and ensure your electronic and industrial projects are built with dependable quality.
