ITT CANNON DBMN25PNK87 High Power Connector System
The Product is a high-reliability, industrial-grade combination connector system offering shielded I/O interfaces suited for space-efficient video, RF, telecom, power, and fiber applications. It incorporates multiple contact types including coaxial, high power, and high voltage, with options for straight or right-angle PCB mounting, European or US footprints, and various finishing treatments such as gold or tin over nickel. Certified for operation from -65°C to 125°C, it supports current ratings up to 40 A for power contacts, with dielectric withstand voltages up to 2800 VAC, and offers excellent shielding to minimize EMI/RFI leakage in demanding environments.
ITT CANNON DBMN25PNK87 High Power Connector System Specifications:
- Operating Temperature: -65°C to 125°C
- Contact Current Rating: Up to 40 A for power contacts, 7.5 A for signal contacts
- Dielectric Withstanding Voltage: 1250 VAC at sea level (signal), 2800 VAC (high voltage)
- Impedance: Less than 1.40 + .03F up to 1GHz
- Insertion Loss: 0.2dB at 1 GHz
- Coaxial Impedance: 50 Ω or 75 Ω options
- Coaxial VSWR: Less than 1.40 + .03F up to 1GHz
- Materials & Finishes: Shells in carbon steel, brass, stainless steel; Gold or tin over nickel platings; Insulators in Teflon or thermoplastic
- Physical Dimensions: Shell sizes ranging approximately from 16.33mm to 76.35mm in various layouts, typical length around 16-24mm
- Mounting Options: PCB through-hole, push-fit, screw, or boardlock; available with European or US footprints; hardware includes captive nuts, PCB posts, or ground grounds
- Additional Features: High voltage and high power contact options, fiber optic versions, shielded and unshielded variants, certifications including UL, CSA, MIL-STD, and NASA GSFC cross references
- Certifications: UL Listed, CSA Certified, MIL-STD, NASA GSFC cross-referenced for space applications
Buy the Buy Cannon Combo D® High Power Connector System Part Number DBMN25PNK87 Online
Discover the high-performance Cannon Combo D connector system available for order online. Designed for space-efficient applications across video, RF, telecom, power, and fiber, it offers excellent shielding, robust construction, and certified reliability from -65°C to 125°C. Suitable for demanding environments, it supports up to 40 A power contacts, 1250 VAC dielectric withstand voltage, and provides options for European or US footprints, with various mounting and finish configurations. Ensure your projects meet industry standards with this trusted, versatile connector system.
Order your Cannon Combo D® High Power Connector System DBMN25PNK87 today and enhance your project’s reliability with space-grade, shielded I/O technology.
