ITT CANNON DCM21WA4SA197 Shielded D Sub Connector
The Combo D Series D*MM combination D Subminiature Connectors offer a space-saving, shielded I/O interconnect solution with flexible options for custom applications. Designed to optimize space and reduce EMI/RFI leakage, this fully shielded connector integrates multiple interconnect types into one unit. It supports standard and European footprints, features pre-installed coaxial or high-power contacts, and is compatible with various mounting methods including vertical standoffs or 90° brackets. Suitable for high-voltage environments up to 2800 VAC, it operates within -55°C to 125°C, making it ideal for communications, industrial, aerospace, and automotive applications. UL94V-0 compliant.
ITT CANNON DCM21WA4SA197 Shielded D Sub Connector Specifications:
- Wire Gauge Range: AWG 8-26
- Mating Cycles: 50
- Contact Arrangement: 21WA4 (17 contacts size 20, 4 empty size 8 cavities)
- Dielectric Withstanding Voltage: 500 VAC at sea level
- Current Rating Signal Contacts: 7.5 max
- Contact Resistance: 10 milli Ohm max
- Operating Temperature: -55°C to +125°C
- Shell Material: Steel
- Shell Finish: Pure tin over nickel
- Insulator Material: Thermoplastic, UL 94V-0
- Insulator Color: Black
- Contact Type: Solder pot
- Contact Material: Copper alloy
- Contact Finish: Gold flash (Performance Class 3)
- Mounting Method: 120" (3.05mm) Through Hole
Buy the Buy Cannon DSub Combo D Series Part Number DCM21WA4SA197 Online
Enhance your connection reliability with the Shielded D Sub Connector from Cannon’s Combo D Series. Designed for high-voltage, industrial, aerospace, and communication uses, this connector combines multiple interconnect types into a fully shielded unit. It supports UL 94V-0 thermoplastic insulation, features durable steel shells with tin over nickel finish, and provides excellent EMI/RFI shielding. Suitable for PCB mounting with various mounting options, it handles temperatures from -55°C to 125°C and supports up to 2800 VAC for demanding environments. Secure your connections today online for quality and reliability.
Buy Cannon DSub Combo D Series part number DCM21WA4SA197 now and experience reliable high-performance connectivity solutions for industrial, aerospace, and communication applications.
Frequently Asked Questions
Where can I buy ITT CANNON DCM21WA4SA197?
You can click on the BUY or RFQ button to purchase DCM21WA4SA197 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DCM21WA4SA197?
You can download the DCM21WA4SA197 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DCM21WA4SA197?
ITT CANNON
