ITT CANNON DCMAM37P High Power Coaxial Plug
The DCMAM37P is a high-reliability coaxial PCB plug designed for industrial and aerospace applications. It features a 90° angle, robust metal shell with optional gold or tin plating, and supports high power loads up to 40A. The connector accommodates various hardware modifications, including M3 or 4-40 threaded standoffs, push-fit PCB retention, and captive nuts for secure mounting. Suitable for RF, telecom, and high-frequency signals, it ensures low contact resistance, excellent dielectric withstand voltage, and stable impedance matching across a wide temperature range from -65°C to 125°C, making it ideal for demanding environments such as space and military systems.
ITT CANNON DCMAM37P High Power Coaxial Plug Specifications:
- Shell Material: Brass, Tin-Nickel or Gold Plated options
- Size: DE to DD, with optional M3 or 4-40 threads
- Impedance: 75 Ohm* or 50 Ohm* coaxial configurations
- Current Rating: Up to 40 A
- Voltage Rating: 1000 VAC at sea level
- Temperature Range: -65°C to 125°C
- Contact Resistance: 1 mΩ max
- Dielectric Withstanding Voltage: 1000 VAC
- Dielectric: Teflon for coaxial insulation; thermoplastic for high voltage variants
- Connector Finishes: Gold or Tin over copper alloy shells
- Hardware Options: M3/M4-40 threads, captive nuts, push-fit PCB retention
- Dimensions: Shell size varies by model, typical length 66 mm, width approximately 16-17 mm, and height about 13-15 mm
Buy the ITT Cannon DCM37P – Reliable RF Coaxial for Industrial Applications
Order the ITT Cannon DCM37P high power coaxial PCB plug online today. Its robust construction, high current capacity, and versatile mounting options make it an excellent choice for demanding RF and aerospace applications. Designed to operate over a wide temperature range from -65°C to 125°C, it ensures reliable performance under extreme conditions. Easily install this connector with options for M3 or 4-40 threaded standoffs, push-fit PCB retention, and captive nuts. Invest in quality and durability for your high-frequency, high-power systems today.
Get ITT Cannon DCM37P today—built for high power RF, flexible mounting, and long-lasting durability in extreme environments.
Frequently Asked Questions
Where can I buy ITT CANNON DCMAM37P?
You can click on the BUY or RFQ button to purchase DCMAM37P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DCMAM37P?
You can download the DCMAM37P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DCMAM37P?
ITT CANNON
