ITT CANNON DCMM37S High Power Receptacle
The product is a high-power coaxial PCB receptacle designed for industrial, military, and high-reliability applications. It features a 90° angle with a metal bracket, available in multiple sizes (DE to DD) and impedance ratings of 75 Ohm or 50 Ohm. Constructed from durable materials like brass with gold or cadmium plating, it supports high current loads up to 40 A and withstands voltage up to 2800 VAC. The connector offers excellent shielding, low insertion loss, and specific configurations for different mounting and hardware options, ensuring reliable performance in demanding environments.
ITT CANNON DCMM37S High Power Receptacle Specifications:
- Impedance: 75 Ohm or 50 Ohm
- Current Rating: Up to 40 A
- Voltage Withstanding: 2800 VAC
- Body Material: Brass with gold or cadmium plating
- Connector Orientation: 90° angle with metal bracket
- Shell Size: DE to DD
- Materials: Brass, stainless steel, with optional gold or cadmium finishes
- Operating Temperature: -65°C to 125°C
- Contact Resistance: 1 mΩ
- Insulation Resistance: 10^3 Ω at 100V
- Insertion Loss: Less than 0.2dB at 1 GHz
- Impedance Tolerance: Typical ± 5%
- Dimensions: Shell length approximately 66.93 mm (DE size), width about 16.33 mm, height about 24.99 mm
- Connectors enable threaded or push-fit PCB mounting, compliant with military and industrial standards
- Supports various hardware options including boardlock, screw lock, and different post configurations
- Suitable for applications requiring EMI/RFI shielding, high power transmission, and high voltage endurance
- RoHS compliant and available with non-magnetic, low outgassing finishes for space or sensitive environments
Buy the Buy ITT Cannon High Power Coaxial Receptacle Part Number DCMM37S Online
Order the ITT Cannon high power coaxial PCB receptacle DCMM37S online today to ensure your industrial, military, or high-reliability systems benefit from superior shielding, high current capacity, and robust construction. This connector provides excellent performance with low insertion loss and high voltage endurance, ideal for applications demanding EMI/RFI protection, space-efficient design, and durability. Secure your supply of high-quality connectors easily through our seamless online ordering process and enjoy fast delivery to keep your projects on schedule.
Get ITT Cannon high power PCB receptacle DCMM37S today—engineered for high current, voltage endurance, and reliable shielding in demanding conditions.
Frequently Asked Questions
Where can I buy ITT CANNON DCMM37S?
You can click on the BUY or RFQ button to purchase DCMM37S from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DCMM37S?
You can download the DCMM37S datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DCMM37S?
ITT CANNON
