ITT CANNON DD50P1A7NK87 D Subminiature connector
The DD-50P-1A7N-K87 is a high-quality D Subminiature connector with 50 pin contacts, designed for reliable performance in industrial and electronic applications. It features a steel shell with a tin finish, thermoplastic insulators, and gold flash contacts rated for 7.5 A at 85°C, ensuring durability and excellent conductivity. Suitable for wire gauges 20-28 AWG, it withstands up to 1200 VAC dielectric voltage, with 50 mating cycles and a maximum contact resistance of 10 milli Ohm. Designed for both indoor and harsh environments, it offers robust solder termination and easy mounting with a metal bracket.
ITT CANNON DD50P1A7NK87 D Subminiature connector Specifications:
- Number of contacts: 50
- Contact size: 20
- Shell Material: steel
- Shell Finish: tin
- Insulator Material: thermoplastic, UL 94V-0
- Insulator Color: black
- Contact Material: copper alloy
- Contact Finish: gold flash (Performance Class 3)
- Contact Resistance: 10 milli Ohm max
- Current Rating: 7.5 A at 85°C / 5 A at 105°C
- Dielectric Withstanding Voltage: 1200 VAC at sea level
- Operating Temperature: -55°C to +125°C
- Mating Cycles: 50
- Wire Gauge Range: 20-28 AWG
- Contact Type: pinned, turned
- Termination: right angled solder
- Mounting Method: metal bracket with 4-40 captive nut
- Salt Spray Test: 20 hours
Buy the Cannon DD-50P-1A7N-K87 – Reliable D Sub Connector for Industrial Applications
Secure your connectivity with the Cannon DD-50P-1A7N-K87 D Sub connector. Featuring robust steel shell, gold flash contacts, and solder termination, this connector ensures reliable operation in demanding environments. Designed for 50 contacts suitable for 20-28 AWG wires, it withstands 1200 VAC insulation voltage and up to 50 mating cycles. Easy to mount with a metal bracket, it offers excellent durability and conductivity for industrial, military, and electronic applications. Order online now for fast delivery and dependable performance.
Order your Cannon DD-50P-1A7N-K87 series D Sub connector today and ensure dependable, high-quality connections for your industrial projects.
Frequently Asked Questions
Where can I buy ITT CANNON DD50P1A7NK87?
You can click on the BUY or RFQ button to purchase DD50P1A7NK87 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DD50P1A7NK87?
You can download the DD50P1A7NK87 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DD50P1A7NK87?
ITT CANNON
