ITT CANNON DLM5260R Industrial D Sub Connector
This connector features 37 contacts with a durable steel shell and a tin finish, designed for reliable connections in industrial environments. It supports wire gauges from AWG 20-28 and offers a current rating of 7.5 A at 85°C, with dielectric withstand voltage of 1200 VAC. The connector is rated for up to 200 mating cycles and operates in temperatures from -55°C to +125°C. Its solder pot termination and through-hole mounting ensure secure installation in various applications. The contact material is copper alloy with gold over nickel finish, ensuring excellent conductivity and corrosion resistance.
ITT CANNON DLM5260R Industrial D Sub Connector Specifications:
- Number of contacts: 37, contact size: 20
- Shell Material: Steel
- Shell Finish: Tin
- Insulator Material: Thermoplastic, UL 94V-0
- Insulator Color: Black
- Wire Gauge Range: AWG 20-28
- Current Rating: 7.5 A at 85°C / 5 A at 105°C
- Dielectric Withstanding Voltage: 1200 VAC at sea level
- Contact Resistance: 10 milli Ohm max
- Operating Temperature Range: -55°C to +125°C
- Mating Cycles: 200
- Contact Material: Copper alloy
- Contact Finish: Gold over nickel
- Contact Termination: Solder pot
- Mounting Method: Through hole (120 inch / 3.05mm)
Buy the Cannon D-Sub 37-Contact Reliable Connector for Industrial Applications
Secure a high-quality industrial D Sub connector with 37 contacts, steel shell, gold over nickel contacts, and support for AWG 20-28 wires. Designed for durability and reliable performance in harsh environments, this connector supports 200 mating cycles and operates from -55°C to +125°C. With a solder pot termination and through-hole mounting, installation is straightforward. Perfect for automation, control systems, and various electronic applications, it ensures optimal conductivity, corrosion resistance, and long service life, making it an essential component for your projects.
Buy Cannon D-Sub 37-Contact connector now and experience unmatched reliability and performance for your industrial needs.
