ITT CANNON KPT02E1419P Circular Connector
The KPT02E14-19P from ITT Cannon is a versatile, miniature circular connector designed for demanding environments. This MIL-DTL-26482 Series I equivalent features 19 contacts with gold-plated copper alloy solder cups, ensuring reliable electrical performance. Constructed from durable aluminum alloy with olive drab chromate over cadmium plating, it offers environmental sealing IP67, vibration resistance of 200 m/s², and an operating temperature range of -55°C to +125°C. Easy to install with quick bayonet coupling, it is suitable for industrial, military, and commercial applications requiring high durability and precision connections.
ITT CANNON KPT02E1419P Circular Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Contact Material: Copper alloy with gold plating
- Number of Contacts: 19
- Contact Type: Solder Cup
- Contact Plating: Gold plated
- Shell Size: 14
- Water Tightness: IP67 according to DIN 40 050
- Operating Temperature: -55°C to +125°C
- Vibration Resistance: 200 m/s² at 10 to 2000 Hz
- Mating Cycles: 500 cycles minimum
- Contact Rating: 7.5A AWG20
- Insulator Resistance: 5000 MΩ at 25°C
- Test Voltage: 1500 V rms
- Environmental Resistance: Salt spray for 500 hours
Buy the ITT Series 26482 Circular Connector: KPT02E14-19P
Purchase the ITT Cannon KPT02E14-19P circular connector online today and experience high durability, IP67 environmental sealing, and exceptional electrical performance. Designed for demanding industrial, military, and commercial applications, this connector features 19 gold-plated copper contacts, a rugged aluminum alloy shell with protective chromate coating, and a quick bayonet coupling system for effortless installation. With a temperature range from -55°C to +125°C, vibration resistance, and 500 mating cycles, this connector delivers reliable, long-lasting connectivity in harsh environments, making it an essential choice for project success.
Order your ITT Series 26482 KPT02E14-19P today and ensure reliable, rugged connections for demanding industrial and military projects.
Frequently Asked Questions
Where can I buy ITT CANNON KPT02E1419P?
You can click on the BUY or RFQ button to purchase KPT02E1419P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part KPT02E1419P?
You can download the KPT02E1419P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of KPT02E1419P?
ITT CANNON
