ITT CANNON KPT06E106P Durable MIL-DTL-26482 Inline Connector
The KPT series KPT06E10-6P from ITT Cannon is a MIL-DTL-26482 Series I equivalent straight plug connector designed for harsh environments. It features six contacts with copper alloy solder pins, gold plating for reliable connectivity, and a resilient polychloroprene insulator and grommet. The connector's aluminum alloy shell, finished with olive drab chromate over cadmium plating, provides durability and corrosion resistance. It is environmentally sealed to IP67, operates from -55°C to +125°C, withstands 500 mating cycles, and resists vibration from 10 to 2000 Hz at 200 m/s², making it ideal for industrial and military applications.
ITT CANNON KPT06E106P Durable MIL-DTL-26482 Inline Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Contact Material: Copper alloy, gold-plated
- Number of contacts: 6, size 20
- Contact Type: Solder cup
- Water Tightness: IP67 (DIN 40 050, 0.2 bar pressure over 48 hrs)
- Operating Temperature: -55°C to +125°C
- Vibration Resistance: 200 m/s² at 10 to 2000 Hz
- Mating Cycles: 500 minimum
- Contact Rating: 7.5A at AWG20
- Insulator Resistance: ≥5000 MOhm
- Test Voltage: 1500 V rms
- Connector Type: Straight plug with Grommet seal
- Shell Size: 10
- Contact Arrangement: 10-6
- Shell Style: Shell with grommet seal, pin gender
- Safety: Protected to IP67 standard per DIN 40 050
- Certifications: Meets VG95319 standards, with compliance to vibration and environmental sealing
Buy the Cannon Series 26482 MIL-DTL-26482 Connector: KPT06E10-6P
Purchase your Cannon Series 26482 MIL-DTL-26482 KPT06E10-6P connector online today for industrial and military-grade reliability. With IP67 environmental sealing, high temperature tolerance, and vibration resistance, this six-pin connector is ideal for demanding applications. Its rugged aluminum alloy shell and gold-plated copper contacts ensure lasting performance in extreme conditions, from -55°C to +125°C. Designed to withstand 500 mating cycles, it provides secure, low-cost modifications and compatibility with all MIL-DTL-26482 connectors. Trust it to deliver consistent, dependable electrical connections in challenging environments.
Order your Cannon Series 26482 MIL-DTL-26482 KPT06E10-6P connector today and ensure reliable, durable performance in harsh environmental conditions.
Frequently Asked Questions
Where can I buy ITT CANNON KPT06E106P?
You can click on the BUY or RFQ button to purchase KPT06E106P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part KPT06E106P?
You can download the KPT06E106P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of KPT06E106P?
ITT CANNON
