ITT CANNON KPT06F1412P MIL-DTL-26482 Circular Connector
The KPT06F14-12P from ITT Cannon is a high-performance, MIL-DTL-26482 Series I equivalent straight plug connector featuring 12 contacts. Designed for rugged environments, it employs a positive three-point bayonet coupling system for quick and secure connection, with five keyway polarization and high contact density for efficient performance. With an environmental sealing rating of IP68, it withstands harsh conditions. Capable of operating from -55°C to +125°C, it offers durability for up to 500 mating cycles, resists vibration at 200 m/s², and endures salt spray exposure for 500 hours, making it ideal for industrial and military applications requiring reliable, high-quality connectivity.
ITT CANNON KPT06F1412P MIL-DTL-26482 Circular Connector Specifications:
- Shell Style: Straight plug
- Shell Size: 14
- Contact Arrangement: 14-12
- Number of contacts: 8 contacts size 20, 4 contacts size 16
- Contact Type: Solder Cup
- Contact Plating: Gold plated
- Shell Material: Aluminium alloy
- Shell Plating: Olive drab chromate over cadmium plating
- Insulator and Grommet Material: Polychloroprene
- Contact Material: Copper alloy
- Water Tightness: IP67/IP68
- Operating Temperature Range: -55°C to +125°C
- Mating Cycles: 500 min
- Vibration Resistance: 200 m/s² at 10 to 2000 Hz
- Contact Rating: AWG20 7.5A, AWG16 13.0A
- Insulator Resistance: 5000 MΩ
- Test Voltage: 1500 Vms
- Sealing: IP67/IP68 according to DIN 40 050
- Durability: 500 mating cycles
- Material: Aluminium alloy body with olive drab chromate over cadmium plating
- Contacts: Copper alloy with gold plating
Buy the ITTT Cannon KPT06F14-12P – Reliable Mil-Dtl-26482 Connectors for Industrial Applications
Secure your high-performance, MIL-DTL-26482 series connector online today. The KPT06F14-12P offers IP68 sealing, quick bayonet coupling, and durability for harsh environments. Designed for rugged applications, it withstands extreme temperatures from -55°C to +125°C, resists vibration, and endures salt spray exposure up to 500 hours. With 12 contacts and gold-plated copper alloy contacts, this connector guarantees reliable signal and power transmission. Its robust aluminium alloy body, polarizations, and environmentally sealed design make it the ideal choice for industrial, military, and aerospace applications that demand high durability and excellent performance.
Order your ITT Cannon KPT06F14-12P connector today and ensure rugged, reliable connectivity for your industrial and military projects.
Frequently Asked Questions
Where can I buy ITT CANNON KPT06F1412P?
You can click on the BUY or RFQ button to purchase KPT06F1412P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part KPT06F1412P?
You can download the KPT06F1412P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of KPT06F1412P?
ITT CANNON
