ITT CANNON M24308243Z Environmental Connector
The M24308243Z is a high-performance environmental connector series designed for aerospace and ground support applications. Featuring rugged aluminum shells, gold-plated copper alloy contacts, and various mounting styles, these connectors provide superior vibration, moisture, and corrosion resistance. Suitable for both solder and crimp terminations, they meet MIL-C-24308 standards, ensuring reliable operation in harsh environments. The series offers multiple sizes, contact arrangements, and optional float mounting to cater to diverse requirements. Dust caps and potting caps are included for environmental sealing and durability, making it ideal for critical aerospace and defense applications.
ITT CANNON M24308243Z Environmental Connector Specifications:
- Shell Material: Aluminum, cadmium plated with yellow chromate coating
- Contacts: Copper alloy, gold plated, solder pot and crimp types
- Contact Termination: Solder up to #20 AWG; Crimp for #20, #22, #24 AWG stranded wire
- Insulation Resistance: Greater than 5,000 megohms
- Voltage Rating: 600 V AC rms at 25°C
- Vibration Resistance: Exceeds MIL-STD-202A, Method 204, Condition D
- Corrosion Resistance: >50 hours salt spray MIL-STD-202A, Method 101A
- Moisture Resistance: Exceeds MIL-STD-202A, Method 106
- Shock Resistance: Exceeds MIL-STD-202A, Method 213, Condition G
- Air Leakage: Max 1 cubic inch per hour at 30 PSI differential
- Contact Retention Force: Min 8 pounds initially, 5 pounds after 10 cycles
- Operational Altitude: Up to 70,000 feet
Buy the ITTCannon Series D Environmental Connector: M24308243Z
Purchase the ITTCannon Series D environmental connector, model M24308243Z, online today for top-tier aerospace performance. Featuring rugged aluminum shells, gold-plated copper contacts, and MIL-C-24308 compliance, this connector guarantees durability in vibration, moisture, and corrosion-prone environments. Its versatile design includes solder and crimp termination options, multiple sizes, and float mounting capability. With environmental sealing, dust caps, and potting caps included, it’s ideal for aircraft, missile, and ground support equipment. Ensure your aerospace projects meet the highest standards by ordering your connector online now.
Order your ITTCannon Series D environmental connector, M24308243Z today and ensure reliable performance in demanding aerospace and ground support applications.
