ITT CANNON MDM15PBSP Micro-D Connector
The MDM15PBSP is a high-density, microminiature circular connector series designed for demanding aerospace, medical, industrial, and defense applications. Constructed from rugged aluminum shells with electroless nickel finish, it features a liquid crystal polymer insulator, gold-plated copper alloy contacts, and various mounting options including jackposts and threaded inserts. It supports up to 15 contacts with a 0.050 inch spacing, with crimp or solder termination, ensuring reliable electrical performance in extreme environments with temperature ratings up to 200°C and high vibration, shock, and moisture resistance.
ITT CANNON MDM15PBSP Micro-D Connector Specifications:
- Shell Material: 6061-T6 Aluminum alloy with electroless nickel finish
- Insulator Material: Liquid Crystal Polymer, Type GLCP-30F
- Contacts: Copper alloy, gold plated, support up to 15 contacts
- Contact Spacing: 0.050 inches (1.27 mm) centers
- Number of Contacts: 15
- Termination: Crimp or solder, with crimp sleeves
- Temperature Range: -55°C to +200°C
- Electrical Resistance: Max 8 milliohms
- Dielectric Withstanding Voltage: 600 VAC at sea level, 150 VAC @70,000 ft
- Insulation Resistance: Minimum 5000 megaohms
- Mechanical Durability: 500 mating cycles
- Vibration & Shock: Meets MIL standards with no damage or loss of continuity
- Sealing & Moisture Resistance: Compression elastomer seal, suitable for harsh environments
Buy the ITT Series Micro-D .050 Connector: MDM15PBSP
Order the ITT Micro-D Connector MDM15PBSP online today to ensure high-performance, reliable connections in extreme conditions. Designed with rugged aluminum shells, gold-plated contacts, and support for high temperatures up to 200°C, this connector provides dependable, durable connections for aerospace, medical, and industrial applications. Featuring crimp or solder terminations, it withstands harsh vibration, shock, moisture, and extreme temperature ranges, making it ideal for mission-critical systems where reliability is paramount.
Buy ITT Micro-D Connector MDM15PBSP now and experience unmatched reliability and performance in demanding aerospace and industrial environments.
Frequently Asked Questions
Where can I buy ITT CANNON MDM15PBSP?
You can click on the BUY or RFQ button to purchase MDM15PBSP from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MDM15PBSP?
You can download the MDM15PBSP datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MDM15PBSP?
ITT CANNON
