ITT CANNON MDM15PCBR Micro-D High Temperature Connector
The MDM15PCBR is a high-density, microminiature connector designed for demanding aerospace, defense, and industrial applications. It features a rugged aluminum shell with electroless nickel plating, a liquid crystal polymer insulator, and gold-plated copper alloy contacts. Offering 15 contact positions at 0.050-inch spacing, it supports multiple termination types including crimp, solder pot, and PCB mounting. The connector withstands extreme temperatures up to 150°C, has a durable friction/jackscrew coupling, and provides reliable electrical performance with a 3A current rating, high insulation resistance, and resistance to shock, vibration, and harsh environmental conditions.
ITT CANNON MDM15PCBR Micro-D High Temperature Connector Specifications:
- Shell Material: 6061-T6 Aluminum alloy with electroless nickel plating
- Insulator Material: Liquid Crystal Polymer per MIL-M-24519
- Contacts: Copper alloy, gold plated
- Number of Contacts: 15
- Contact Spacing Centers: 0.050 inches (1.27 mm)
- Contact Type: P - Pin / S - Socket
- Termination Types: Crimp, solder pot, or PCB mounting
- Current Rating: 3 amps
- Dielectric Withstanding Voltage: 600 VAC at sea level, 150 VAC at 70,000 ft altitude
- Insulation Resistance: > 100 megaohms
- Shock, Vibration: Meets MIL-STD-202; shock 50 G, vibration 20 G for 12 hrs
- Temperature Range: -55°C to +150°C
- Durability: 500 cycles of mating/unmating
- Hardware: Copper alloy, gold plated with passivation; stainless steel jackposts
- Seal: Compression silicone elastomer interface
- Dimensions: Consult manufacturer for detailed measurements
Buy the Buy ITT Cannon Micro-D High Temperature Connector Part Number MDM15PCBR Online
Purchase your ITT Cannon MDM15PCBR micro-d connector online today and benefit from superior durability, high-temperature operation up to 150°C, and excellent environmental resistance. Designed for critical applications in aerospace, defense, and industrial markets, this connector provides reliable electrical performance with gold-plated contacts, robust aluminum construction, and versatile termination options including crimp, solder pot, and PCB mounts. Experience quick and secure mating in harsh conditions and ensure long-term system integrity with this proven, high-density interconnect solution.
Order your ITT Cannon MDM15PCBR high reliability micro-d connector today and ensure optimal performance in demanding aerospace and industrial environments.
Frequently Asked Questions
Where can I buy ITT CANNON MDM15PCBR?
You can click on the BUY or RFQ button to purchase MDM15PCBR from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MDM15PCBR?
You can download the MDM15PCBR datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MDM15PCBR?
ITT CANNON
