ITT CANNON MDM15PCBRA174F222 Micro Connector
The Micro Series MDM-15PCBR-A174-F222 is a high-quality micro connector with a 15-contact pin arrangement, designed for reliable electrical connections in compact electronic systems. Made with gold-plated copper alloy contacts, it features a right-angle PCB termination for easy mounting. The aluminum shell with electroless nickel finish ensures durability, resistance to corrosion, and thermal stability. Suitable for applications requiring a maximum current of 3A, it withstands dielectric voltages up to 600 VAC, making it ideal for demanding electronic and industrial use. Its insulation materials and robust construction guarantee long-lasting performance under various environmental conditions.
ITT CANNON MDM15PCBRA174F222 Micro Connector Specifications:
- Contact Material: Gold-plated copper alloy
- Contact Arrangement: 15 Contact, pin gender
- Termination Type: Right angle PCB
- Shell Material: Aluminum
- Shell Finish: Electroless Nickel
- Insulator Material: Liquid crystalline polymer (contact size 9 to 100), Diallyl phthalate (contacts 7C2, 24C4)
- Current Rating: 3A max
- Dielectric Withstanding Voltage: 600 VAC at sea level, 150 VAC at 70,000' altitude
- Insulator Resistance: 5000 megohms min
- Thermal Shock: -55°C/+200°C
- Physical Shock: 50 G’s, 3 axes, 6 ms duration sawtooth pulse
- Vibration: 20 G’s, 10-2000 Hz, 12 hours
- Durability: 500 mating cycles, 500 CPH max
- Moisture Resistance: Insulator resistance > 100 megohms
- Salt Spray: 48 hours
Buy the Buy Cannon Micro Part Number MDM-15PCBR-A174-F222 Online
Order the Cannon Micro Connector MDM-15PCBR-A174-F222 online today. This high-performance connector features a 15-contact pin arrangement, gold-plated copper alloy contacts, and a durable aluminum shell with electroless nickel finish. Its compact right-angle PCB termination offers easy installation while providing excellent electrical conductivity and corrosion resistance. Suitable for demanding industrial, aerospace, or electronic applications, it withstands thermal shocks, vibration, and moisture. Purchase now for long-lasting, reliable connections designed to meet rigorous technical standards and ensure system performance.
Get Cannon MDM-15PCBR-A174-F222 today—designed for reliable electrical connections in compact industrial and electronic systems.
Frequently Asked Questions
Where can I buy ITT CANNON MDM15PCBRA174F222?
You can click on the BUY or RFQ button to purchase MDM15PCBRA174F222 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MDM15PCBRA174F222?
You can download the MDM15PCBRA174F222 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MDM15PCBRA174F222?
ITT CANNON
