ITT CANNON MDM15SSB Micro Connector
The MDM-15SSB is a 15-way solder receptacle connector featuring gold-plated copper contacts and a durable aluminum shell with yellow chromate/cadmium over nickel finish. Designed with a friction coupling system, it supports a maximum current of 3A and withstands dielectric voltages up to 600 VAC at sea level. Its insulator is made from high-performance liquid crystalline polymer, suitable for rugged industrial environments. Operating temperature ranges from -55°C to +125°C, and it offers high insulator resistance over 5000 megohms. The connector is resistant to thermal shock, vibration, moisture, and salt spray, ensuring reliable, interference-free connections in demanding conditions.
ITT CANNON MDM15SSB Micro Connector Specifications:
- Number of contacts: 15
- Contact Material: Gold-plated copper alloy
- Shell Material: Aluminum
- Shell Finish: Yellow Chromate/Cadmium over Nickel
- Termination Type: Solder pot for #26AWG max. wire
- Current Rating: 3A max.
- Dielectric Withstanding Voltage: 600 VAC at sea level
- Insulator Material: Liquid crystalline polymer or Diallyl phthalate
- Operating Temperature Range: -55°C to +125°C
- Insulator Resistance: > 5000 megohms
- Resistance: 8 milliohms max.
- Hardware: .092 diameter mounting holes
- Coupling: Friction
- Vibration Resistance: 20G's, 10-2000Hz, 12 hours
- Durability: 500 mating cycles
- Moisture Resistance: Insulator resistance > 100 megohms
- Salt Spray Resistance: 48 hours
Buy the Cannon Series MICRO Micro Connector: MDM15SSB
Enhance your industrial connectivity with the Micro Connector featuring 15 gold-plated copper contacts and a durable aluminum shell. Designed for harsh environments, this high-performance receptacle provides secure, interference-free connections with excellent electromagnetic shielding. Its rugged construction supports high temperature operation from -55°C to +125°C and resists thermal shock, vibration, moisture, and salt spray, making it ideal for demanding industrial, aerospace, and military applications. Easily connect and disconnect with a durable solder pot termination and friction coupling system for reliable performance over thousands of cycles.
Buy Cannon MDM15SSB now and experience unmatched reliability for industrial applications with rugged, high-performance connection solutions.
