ITT CANNON MDM37PH003L Micro D Plug Connector
The MDM-37PH003L is a 37-position Micro D plug connector designed for rugged industrial and electronic applications. It features gold-plated copper alloy contacts for reliable conductivity and a liquid crystalline polymer insulator for durability. The aluminum shell, finished with yellow chromate/cadmium over nickel, provides corrosion resistance. With a jackscrew coupling mechanism, it ensures secure connections with an operational temperature range from -55°C to 125°C. Rated for 3A current, it withstands up to 500 mating cycles, making it ideal for demanding environments requiring high durability and performance.
ITT CANNON MDM37PH003L Micro D Plug Connector Specifications:
- Contact Material: gold-plated copper alloy
- Contact Resistance: 8 milliohms max
- Termination Type: crimp, 18" Min, #26AWG
- Shell Material: Aluminum
- Shell Finish: Yellow Chromate/Cadmium over Nickel
- Insulator Material: liquid crystalline polymer
- Current Rating: 3A max
- Dielectric Withstanding Voltage: 600 VAC at sea level, 150 VAC at 70,000' altitude
- Insulator Resistance: 5000 megaohms min
- Thermal Shock: -55°C to +125°C
- Physical Shock: 50 G's, 3 axes, 6 ms pulse
- Vibration: 20 G's, 10-2000 Hz, 12 hours
- Durability: 500 mating/unmating cycles
- Moisture Resistance: insulator resistance > 100 megaohms
- Salt Spray Resistance: 48 hours
Buy the Buy Cannon Micro Plug Connector Part Number MDM-37PH03L Online
Discover the reliable and durable Micro D plug connector designed for demanding industrial applications. With gold-plated contacts, an aluminum shell finish, and robust insulators, it guarantees excellent conductivity and corrosion resistance. Rated for 3A current and withstanding up to 500 mating cycles, it offers superior performance across temperature ranges from -55°C to 125°C. Perfect for complex electronic systems, the MDM-37PH03L ensures secure connections in harsh environments. Purchase online now to enhance your project’s reliability and precision.
Order your Cannon Series MDM-37PH03L micro D plug connector today and ensure reliable, high-performance connections for your industrial projects.
Frequently Asked Questions
Where can I buy ITT CANNON MDM37PH003L?
You can click on the BUY or RFQ button to purchase MDM37PH003L from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MDM37PH003L?
You can download the MDM37PH003L datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MDM37PH003L?
ITT CANNON
