ITT CANNON MKJ3B6F813SN Circular Bayonet Connector
The ITT CANNON MKJ3B6F8-13SN is a high-performance circular bayonet connector from the Trinity MKJ series. Designed for demanding environments, this connector offers secure and rapid mating with a bayonet coupling mechanism. It features 23 contacts of size 13, aluminum/electroless nickel plating for corrosion resistance, and a straight plug configuration. The connector is rated for a maximum current of 5 Amps and a voltage of 500 VAC RMS at sea level. It meets stringent vibration and shock requirements as defined by MIL-STD-1344, and provides effective EMI shielding. Ideal for industrial automation, aerospace, and military applications.
ITT CANNON MKJ3B6F813SN Circular Bayonet Connector Specifications:
- series: Bayonet Coupling
- class: Environmental Plug and Receptacle Threaded Accessory Attachment
- shell_style: Straight Plug
- shell_size: 6
- plating: Aluminum/Electroless Nickel
- contact_arrangement: 23 Contacts Size 13
- gender: Socket, Crimp, Removable
- polarization: Normal (150° 210°)
- contact_size_spacing: #23 / 0.076 inches (1.9 mm)
- wire_acomodiation: #22 - #28 AWG
- current_rating: 5 Amps Maximum
- voltage_rating: 500 VAC RMS Sea Level
- insulator_resistance: 5000 Megaohms Minimum
- operating_temperature: -55°/+150°
- contact_resistance: 8 Milliohms Maximum
- vibration: 20 g′ in Accordance with MIL-STD-1344 Method 2005, Condition IV
- shock: 300 g′ (MKJ1) 50 g′ (MKJ0 and MKJ4) in Accordance with MIL-STD-1344 Method 2004, Condition E
- emi_shielding_effectiveness: 40dB Attenuation, 100 MHz to 1000 MHz
