ITT CANNON MS3106E1810P Circular connector
The MS3106E18-10P is a high-quality circular connector with a threaded coupling design. It features a shell size 18, 18-10 contact arrangement with 4 solder cup contacts made of copper alloy, hard silver plated for durability. The connector has IP65 protection, withstands salt spray for 500 hours, and operates efficiently within -55°C to +125°C. Suitable for industrial and military applications, it ensures secure mating with 500 mating cycles, and has a locking torque of 8 Nm maximum, making it reliable for demanding environments.
ITT CANNON MS3106E1810P Circular connector Specifications:
- Shell Size: 18
- Contact Arrangement: 18-10
- Number of contacts: 4, size 12
- Contact Type: Solder Cup
- Contact Plating: Hard silver
- Shell Material: Aluminium alloy with olive drab chromate coating over cadmium plating
- Insulator Material: Neoprene
- Operating Temperature: -55°C to +125°C
- Ingress Protection: IP65 according to DIN 40 050
- Salt Spray Resistance: 500 hours
- Mating Cycles: 500
- Separation Force per Contact: 1.5N
- Coupling Torque: Closing max 8 Nm, opening min 0.58 Nm
- Contact Retention: 55N
- Insulator and Grommet Material: Neoprene
- Wire Stripping Range: 6.2 mm
- Test Voltage: 1600 Vrms
- Insulator Resistance: >1000 MO
- Contact Resistance: 3 mo
- Air and Creepage Path: 41.4 mm
Buy the Buy Cannon Circular Connector Part Number MS3106E18-10P Online
Secure your industrial and military projects by ordering the Cannon MS3106E18-10P circular connector online. Designed with a durable aluminium shell, IP65 sealing, and high-quality solder cup contacts, this connector offers excellent performance in harsh environments. It withstands salt spray, operates efficiently at temperatures from -55°C to +125°C, and supports up to 500 mating cycles for long-term reliability. Easy to install with a coupling torque of 8 Nm, making it a dependable choice for critical applications.
Order your Cannon MS3106E18-10P circular connector today and ensure your projects have reliable, durable, and secure electrical connections for demanding environments.
