ITT CANNON MS3106E2029PW Circular Connector
The MS3106E20-29PW is a high-quality, threaded circular connector designed for durable, reliable electrical connections in industrial and aerospace applications. It features a straight shell style with a pin gender, 20 shell size, and 17 solder cup contacts with hard silver plating. The connector offers IP65 protection, salt spray resistance for 500 hours, and a maximum of 500 mating cycles. Suitable for voltages over 50V when used per standards, it has robust aluminum alloy shells with olive drab chromate coating. Ideal for demanding environments requiring secure and stable connections.
ITT CANNON MS3106E2029PW Circular Connector Specifications:
- Shell Style: Straight shell with threaded coupling
- Shell Material: Aluminum alloy with olive drab chromate coating
- Contact Type: Solder cup, 17 contacts, size 16
- Contact Material: Copper alloy with hard silver plating
- Contact Resistance: Low resistance specified, typically less than 5 milliohms
- Contact Rating: Suitable for voltages >50V when used as per standards
- Operating Voltage: Designed for voltages exceeding 50V with proper standards compliance
- Insulator Resistance: >1000 MΩ according to VG95319 and VG95210
- Test Voltage: 1600 Vrms
- Air and Creepage Paths: Min 1.4mm
- Ambient Temperature Range: -55°C to +125°C
- Ingress Protection: IP65 (DIN 40 050)
- Salt Spray Resistance: 500 hours
- Mating Cycles: 500
- Coupling Torque: Closing max 9 Nm, Opening min 0.7 Nm
- Contact Retention Force: 35 N
- Wire Stripping: 6.2 mm length
- Gasket Material: Neoprene
- Shell Size: 20
- Number of Contacts: 17
Buy the Cannon Series MIL-C-5015 Circular Connector: MS3106E20-29PW
Purchase the Cannon Series MIL-C-5015 Circular Connector MS3106E20-29PW online today for dependable, high-performance electrical connections. Designed for demanding industrial and aerospace environments, it features a sturdy aluminum alloy shell with olive drab chromate coating, 17 solder cup contacts, and IP65 protection against dust and water. With salt spray resistance, 500 mating cycles, and a wide temperature range, this connector ensures durability and reliable performance in challenging conditions. Buy now to enhance your project's connection quality.
Order your Cannon Series MIL-C-5015 MS3106E20-29PW connector today and ensure your assemblies are protected with reliable, rugged industrial-grade connections.
Frequently Asked Questions
Where can I buy ITT CANNON MS3106E2029PW?
You can click on the BUY or RFQ button to purchase MS3106E2029PW from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3106E2029PW?
You can download the MS3106E2029PW datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3106E2029PW?
ITT CANNON
