ITT CANNON MS3106F16S4P Circular Connector
The MS3106F16S-4P from ITT Cannon is a MIL-DTL-5015 series straight circular connector with two solder cup contacts. Designed for heavy-duty applications, it features a durable aluminum alloy shell with olive drab chromate over cadmium plating, ensuring corrosion resistance. The connector is IP65 rated for environmental sealing, capable of withstanding salt spray for 500 hours, shocks, and vibrations. It supports electrical performance with a contact rating suitable for high-current applications and operates within a temperature range of -55°C to +125°C. The connector offers quick threaded coupling, with at least 5,000 mating cycles, making it ideal for military, aerospace, industrial, and harsh environment use.
ITT CANNON MS3106F16S4P Circular Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Number of contacts: 2, size 16S, solder cup type
- Contact Material: Copper alloy with silver plating
- Contact Resistance: aaN
- Operating Voltage: Suitable for voltages greater than 50V according to DIN VDE 410 and IEC 60364-4-41
- Insulator Resistance: > 1000 MΩ per VG95319 and VG95210 standards
- Test Voltage: 2500 Vrms
- Air and Creepage Paths: Minimum 2.8 mm
- Ambient Temperature: -55°C to +125°C
- Salt Spray Resistance: 500 hours
- Mating Cycles: Minimum 500
- Shell Style: Threaded coupling with straight plug
- Shell Size: 16S
- Sealing: IP65 according to DIN 40 050
- Coupling Torque: Closing max 5.5 Nm, opening min 0.46 Nm
- Gasket Material: Neoprene
- Housing Material: Aluminum alloy
- Insulator Material: Neoprene
- Wire Stripping Length: 6.2 mm
Buy the Buy ITT Circular Connector Part Number MS3106F16S4P Online
Purchase the ITT Circular Connector MS3106F16S-4P online today and benefit from high durability and reliable electrical performance. Designed for demanding environments, this connector features corrosion-resistant aluminum alloy shell with olive drab chromate over cadmium plating, ensuring longevity even in salt spray, vibration, and extreme temperatures. Its IP65 sealing provides excellent environmental protection, making it ideal for military, aerospace, and industrial applications. With at least 5,000 mating cycles, quick threaded coupling, and high-current solder cup contacts, it guarantees secure, long-lasting connections for your project needs.
Order your ITT Series MS3106F16S-4P today and ensure reliable secure connections with durable construction suitable for harsh environments.
Frequently Asked Questions
Where can I buy ITT CANNON MS3106F16S4P?
You can click on the BUY or RFQ button to purchase MS3106F16S4P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3106F16S4P?
You can download the MS3106F16S4P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3106F16S4P?
ITT CANNON
