ITT CANNON MS3106F16S8P MIL-DTL-5015 Connector
The ITT Cannon MS3106F16S-8P is a MIL-DTL-5015 series straight plug connector with five contacts, designed for high reliability and durability. It features a miniature circular shell made of aluminum alloy with olive drab chromate over cadmium plating, offering excellent corrosion resistance. The connector is available in multiple shell styles and sizes, with a single key/keyway polarization for correct mating. It provides environmental sealing with IP67 protection, withstands extreme temperatures from -55°C to +125°C, and is capable of 500 mating cycles. The contacts are made of brass or copper alloy with silver plating, suitable for demanding military, aerospace, industrial, and defense applications. It employs quick threaded coupling for secure and rapid connection, combining high density contact arrangements with a lightweight and cost-effective design.
ITT CANNON MS3106F16S8P MIL-DTL-5015 Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate coating over cadmium plating
- Number of Contacts: 5 contacts size 16S
- Contact Type: Solder Cup
- Contact Plating: Hard silver
- Operating Temperature: -55°C to +125°C
- Ingress Protection: IP67
- Salt Spray Resistance: 500 hours
- Mating Cycles: 500 times
- Coupling Torque: Closing 5.5 Nm max, Opening 0.46 Nm min
- Shell Style: Threaded coupling, straight plug
- Endbell Style: Endbell with cable clamp
- Insulator Material: Neoprene
- Shell Size: 16S
- Contact Resistance: Aan
- Test Voltage: 1600 Vrms
- Insulator Resistance: > 1000 MO
- Air and Creepage Paths: 1.4mm
- Operating Voltage: Must comply with IEC 60364-4-41 for voltages > 50V
- Dimensions: Refer to manufacturer datasheet
Buy the Buy Cannon Circular Connector Part Number MS3106F16S8P Online
Purchase the Cannon MS3106F16S8P circular connector online today to ensure reliable, corrosion-resistant connections for demanding military, aerospace, and industrial environments. Featuring a lightweight aluminum shell with olive drab chromate over cadmium plating, this MIL-DTL-5015 series connector offers IP67 environmental sealing, withstands extreme temperatures from -55°C to +125°C, and supports 500 mating cycles. Its five solder cup contacts with silver plating provide excellent electrical performance. Designed for quick threaded coupling, this durable connector is ideal for critical industry applications requiring high reliability and secure connections. Order now to enhance your project’s performance and durability.
Buy Cannon MS3106F16S8P now and experience unmatched reliability and high-density connection suited for military, aerospace, and industrial applications.
Frequently Asked Questions
Where can I buy ITT CANNON MS3106F16S8P?
You can click on the BUY or RFQ button to purchase MS3106F16S8P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3106F16S8P?
You can download the MS3106F16S8P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3106F16S8P?
ITT CANNON
