ITT CANNON MS3106F2410S Circular Connector
The MS3106F24-10S from ITT Cannon is a MIL-DTL-5015 series straight plug connector with 7 contacts, designed for rugged environments in defense, aerospace, and industrial applications. It features an aluminum alloy shell with olive drab chromate over cadmium plating, providing excellent durability and corrosion resistance. The connector supports quick threaded coupling, environmental sealing, and withstands temperatures from -55°C to +125°C. With 500 mating cycles, IP67 protection, and brass or copper alloy contacts with silver plating, it ensures reliable electrical connections in demanding conditions.
ITT CANNON MS3106F2410S Circular Connector Specifications:
- Shell Material: Aluminum alloy
- Shell Plating: Olive drab chromate over cadmium
- Contact Material: Copper alloy with silver plating
- Number of Contacts: 7
- Contact Arrangement: 24-10
- Contact Type: Solder cup
- Contact Resistance: 1mΩ
- Operating Temperature Range: -55°C to +125°C
- Endbell Style: With cable clamp
- Ingress Protection: IP65/IP67
- Salt Spray Resistance: 500 hours
- Mating Cycles: 500
- Coupling Torque: Max 14 Nm / Min 0.8 Nm
- Contact Retention: 80 N
- Environmental Resistance: Vibration, corrosion, salt spray
- Crimping / Stripping: 11.8 mm stripping length
- Insulator Resistance: > 1000 MO
- Test Voltage: 1600 Vrms
Buy the Buy ITT Cannon Connector Part Number MS3106F24-10S Online
Explore the high-quality MS3106F24-10S circular connector from ITT Cannon, engineered for demanding environments in defense, aerospace, and industrial sectors. Featuring corrosion-resistant aluminum alloy shell, silver-plated contacts, and IP67 environmental sealing, this connector supports 500 mating cycles and withstands temperatures from -55°C to +125°C. Its quick threaded coupling ensures secure connections, while salt spray resistance and vibration durability make it ideal for extreme conditions. Purchase online today to ensure reliable, durable electronic connections for your critical applications.
Buy ITT Cannon MS3106F24-10S now and experience unmatched reliability and performance in harsh environments with corrosion-resistant construction and secure sealing.
