ITT CANNON MS3106F245P Circular Connector
The MS3106F24-5P is a high-quality circular connector designed for industrial and military applications, featuring a straight shell style plug with threaded coupling. It has 16 solder cup contacts plated with hard silver, suitable for high-reliability connections. The connector offers IP65 protection, salt spray resistance for 500 hours, and can withstand operating temperatures from -55°C to +125°C. It supports up to 500 mating cycles, with a maximum coupling torque of 14 Nm, making it ideal for demanding environments requiring secure, durable electrical connections. Suitable for various wiring and automation projects.
ITT CANNON MS3106F245P Circular Connector Specifications:
- Shell Material: Aluminium alloy with olive drab chromate coating over cadmium plating
- Contact Arrangement: 24-5, 16 contacts size 16
- Contact Type: Solder Cup, Contact Plating: Hard silver
- Contact Resistance: aan
- Operating Voltage: ≥50V with compliance to DIN VDE 410, IEC 60364-4-41
- Insulator Resistance: >1000 MO according to VG95319, VG95210
- Test Voltage: 1600 Vrms
- Air and Creepage Paths: 1.4mm minimum
- Ambient Temperature Range: -55°C to +125°C
- Protection Grade: IP65 according to DIN 40050
- Salt Spray Resistance: 500 hours
- Mating Cycles: 500 minimum
- Coupling Torque: Closing 14 Nm max, Opening 0.8 Nm min
- Shell Size: 24
- Gage: VG95234, part 4
- Wire Stripping Length: 6.2 mm
- Shell Style: Threaded, straight connector with cable clamp
- Gasket Material: Neoprene
- Seal: No shielding
Buy the Cannon Series MIL-DTL 5015 Circular Connector: MS3106F24-5P
Experience the durability and reliability of the Cannon MS3106F24-5P circular connector. Designed for harsh environments, it features robust aluminium alloy shell, IP65 protection, salt spray resistance for 500 hours, and a wide temperature range from -55°C to +125°C. Its 16 solder cup contacts with hard silver plating ensure secure and long-lasting electrical connections. With a maximum coupling torque of 14 Nm and support for 500 mating cycles, this connector is perfect for industrial automation, military, and aerospace applications. Purchase online for quick, secure delivery.
Get Cannon MS3106F24-5P today—built for high-reliability industrial and military electrical connections in demanding environments.
Frequently Asked Questions
Where can I buy ITT CANNON MS3106F245P?
You can click on the BUY or RFQ button to purchase MS3106F245P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3106F245P?
You can download the MS3106F245P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3106F245P?
ITT CANNON
