ITT CANNON MS3116F2255S military connector
The ITT Cannon MS3116F22-55S is a MIL-DTL-26482 Series I straight plug connector featuring 55 contacts. Designed for demanding environments, this environmentally sealed connector offers high durability with resistance to extreme shock, vibration, and environmental exposure. It is intermateable and interchangeable with MIL-C-26482 and VG95328 connectors, featuring a self-leveling, three-point bayonet coupling for quick and reliable connection. The connector includes precise keyway alignment, a high contact density, and operates effectively within a temperature range of -55°C to +125°C. Made from aluminum alloy with olive drab chromate over cadmium plating, it incorporates copper alloy solder socket contacts with gold plating, and utilizes resilient polychlorprene insulators and grommets. The connector provides an insulation resistance of 5000 MΩ at 25°C and supports up to 500 mating cycles at an operating voltage of 1000 VAC.
ITT CANNON MS3116F2255S military connector Specifications:
- Connector Type: MIL-DTL-26482 Series I
- Configuration: Straight plug
- Contacts: 55 high-density copper alloy solder socket contacts, gold plated
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Operating Temperature Range: -55°C to +125°C
- Ingress Protection: Environmentally sealed against moisture and contaminants
- Coupling System: Self-leveling, three-point bayonet locking
- Insulation Resistance: 5000 MΩ at 25°C
- Mating Cycles: Up to 500 cycles
- Voltage Rating: 1000 VAC
- Keyway: Precise alignment for correct mated configuration
- Grommets: Resilient polychlorprene for environmental sealing
- Application: Military, aerospace, demanding environmental conditions
Buy the Amphenol Series MS3116F22-55S MIL-DTL-26482 Connector: 55 Contacts
Order the Amphenol MS3116F22-55S straight plug connector today and ensure your systems operate reliably in extreme conditions. This high-performance MIL-DTL-26482 Series I connector features 55 contacts, corrosion-resistant aluminum alloy shell, and gold-plated contacts for superior electrical contact. Designed for demanding applications, it supports up to 500 mating cycles and operates at voltages up to 1000 VAC. Its environmentally sealed design prevents moisture ingress, making it ideal for aerospace, military, and harsh industrial environments. Purchase online for fast delivery and guaranteed authenticity.
Buy Amphenol MS3116F22-55S now and experience unmatched reliability and performance in harsh environments with quick bayonet coupling and high durability.
Frequently Asked Questions
Where can I buy ITT CANNON MS3116F2255S?
You can click on the BUY or RFQ button to purchase MS3116F2255S from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3116F2255S?
You can download the MS3116F2255S datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3116F2255S?
ITT CANNON
