ITT CANNON MS3126F1626S Circular Connector
The MS3126F16-26S from ITT Cannon is a MIL-DTL-26482 Series I straight plug connector with 26 contacts, designed for harsh environments. Made from durable aluminum alloy with olive drab chromate over cadmium plating, it features copper alloy, gold-plated crimp contacts that ensure reliable electrical performance. The connector provides environmental sealing, withstands extreme temperatures from -55°C to +125°C, resisting shock, vibration, and corrosion. It supports up to 500 mating cycles, operates at 1000 VAC, and is compatible with MIL-C-26482 standards, suitable for demanding industrial and military applications.
ITT CANNON MS3126F1626S Circular Connector Specifications:
- Shell Style: Straight plug
- Shell Material: Aluminum alloy
- Shell Plating: Olive drab chromate over cadmium plating
- Contact Arrangement: 16-26
- Number of contacts: 26, size 20
- Contact Type: Crimp contacts, copper alloy, gold plated
- Water Tightness: IP67 according to DIN 40 050
- Operating Temperature Range: -55°C to +125°C
- Vibration: 200 m/s² at 10 to 2000 Hz
- Mating Cycles: Minimum 500
- Contact Rating: 7.5A at AWG20
- Insulator and Grommet Material: Polychloroprene
- Test Voltage: 1500 V RMS
- Operating Voltage: Up to 1000 VAC
- Insulator Resistance: ≥5000 MΩ
- Safety Standards: Sealed to VG95319 Part 2, Test No. 5.9.2
- Environmental Resistance: Resistant to shock, vibration, corrosion
- Certification: IP67 environmental sealing
- Compatibility: Interchangeable with MIL-C-26482 and VG95328 series
Buy the Cannon Series MIL-DTL 26482 MS3126F1626S: Circular Connector with 26 Contacts
Enhance your equipment's reliability with the Cannon Circular Connector featuring 26 contacts, rugged aluminum alloy construction, and IP67 sealing. Designed for harsh environments, it withstands extreme temperatures from -55°C to +125°C, supports over 500 mating cycles, and offers excellent resistance to shock, vibration, and corrosion. Whether for military, aerospace, or industrial uses, this connector ensures secure, high-quality connections with precise alignment and environmental sealing, making it an ideal choice for demanding applications requiring durability, high performance, and long-term reliability.
Buy Cannon MS3126F1626S now and experience unmatched reliability, environmental protection, and durable performance for demanding industrial applications.
Frequently Asked Questions
Where can I buy ITT CANNON MS3126F1626S?
You can click on the BUY or RFQ button to purchase MS3126F1626S from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3126F1626S?
You can download the MS3126F1626S datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3126F1626S?
ITT CANNON
