ITT CANNON NPDFT1BNLT4 Panel Drain Connector
The NPDFT-1-BN-L-T4 is a high-current panel drain connector designed for industrial applications. Featuring a brown shell style and a secondary locking pin, it ensures secure connections with a maximum current rating of 400A. The connector uses a 400A threaded post M12 for reliable contact and has an ingress protection rating of IP67. It operates within a temperature range of -30°C to +125°C, with a voltage rating of 1000Vac. Crafted from high-temperature thermoplastic, it provides excellent durability and safety in demanding environments, suitable for power and control systems with robust electrical and mechanical features.
ITT CANNON NPDFT1BNLT4 Panel Drain Connector Specifications:
- Shell Material: High temperature thermoplastic
- Shell Style: Phase 1
- Color: Brown
- Locking Type: Secondary locking pin fitted to drain connector
- Contact Type: 400A threaded post M12
- Maximum Current Rating: 400 A
- Maximum Rated Voltage to Earth: 2KVac | 3kKVde
- Operating Voltage: 1000Vac
- Insulation Resistance: <5 Mohms @500Vdc
- Ingress Protection: IP67
- Operating Temperature Range: -30°C to +125°C
- Protection Against Electrical Shock: IP2x
- Flammability: UL94-VO
- Contact Retention: Nylon Pin
- Mating Method: Bayonet
- Mating Cycles: 500
Buy the Cannon Series RLOCK Circular Powerlock: NPDFT-1-BN-L-T4
Enhance your power and control systems with the durable Cannon Series Panel Drain Connector. Designed for high current up to 400A and featuring IP67 protection, it ensures reliable performance in harsh environments. The bayonet mating method and nylon contact retention provide secure, repeated connections, while the thermoplastic shell withstands temperature extremes from -30°C to +125°C. Easy to install and engineered for safety, this connector is ideal for industrial automation, power distribution, and control system applications requiring robust and long-lasting electrical connections.
Order your Cannon Series RLOCK NPDFT-1-BN-L-T4 today and ensure secure, high-current electrical connections for demanding industrial applications.
Frequently Asked Questions
Where can I buy ITT CANNON NPDFT1BNLT4?
You can click on the BUY or RFQ button to purchase NPDFT1BNLT4 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part NPDFT1BNLT4?
You can download the NPDFT1BNLT4 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of NPDFT1BNLT4?
ITT CANNON
