ITT CANNON NPDFT3GYLT6 Panel Drain
The NPDFT3GYLT6 is a high-capacity circular panel drain with a grey high-temperature thermoplastic shell, designed for electrical grounding and connection in industrial environments. It features a 660A threaded post M12 contact, IP67 ingress protection, and bayonet mating method with 500 cycles. The device supports operating voltages up to 1000Vac, with insulation resistance below 5 Mohms at 500Vdc. Its secondary locking pin ensures secure and reliable connections, making it suitable for demanding applications where safety and durability are essential.
ITT CANNON NPDFT3GYLT6 Panel Drain Specifications:
- Shell Material: High temperature thermoplastic
- Color: Grey
- Locking Type: Secondary locking pin fitted to drain connector
- Contact Type: 660A threaded post M12
- Maximum current rating: 660 A
- Maximum rated voltage to earth: 2KVac | 3kKVde
- Operating voltage: 1000Vac
- Operating temperature range: -30°C to +125°C
- Insulation resistance: Less than 5 Mohms at 500Vdc
- Ingress protection: IP67 (mated)
- Protection against electrical shock: IP2x
- Flammability: UL94-VO
- Mating method: Bayonet
- Number of mating cycles: 500
Buy the Cannon Series Powerlock Panel Drain: NPDFT3GYLT6
Secure your electrical grounding and connection needs with the Cannon Series Powerlock Panel Drain NPDFT3GYLT6. With a robust thermoplastic shell, 660A current capacity, IP67 protection, and bayonet coupling for easy mating, this device offers exceptional durability and reliability in demanding industrial environments. Its secondary locking pin ensures safety and secure connections. Perfect for applications requiring high voltage, frequent connection cycles, and environmental resistance, this panel drain supports operational voltages up to 1000Vac and withstands extreme temperatures from -30°C to +125°C, making it an ideal choice for critical power systems.
Order your Cannon Series Powerlock Panel Drain NPDFT3GYLT6 today and ensure safe, reliable electrical connections with superior durability.
Frequently Asked Questions
Where can I buy ITT CANNON NPDFT3GYLT6?
You can click on the BUY or RFQ button to purchase NPDFT3GYLT6 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part NPDFT3GYLT6?
You can download the NPDFT3GYLT6 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of NPDFT3GYLT6?
ITT CANNON
