ITT CANNON ZDB25S1AKN146 D Sub Connector
This high-quality D Sub connector offers reliable electrical performance with 25 contacts, gold flash finish, and a robust steel shell. Suitable for industrial and electronic applications, it features a tin shell finish and thermoplastic insulator rated UL 94V-0. Designed for easy mounting with a plastic bracket and screw lock, it supports wire gauge ranges from AWG 20 to AWG 28 and withstands voltages up to 1000 VAC. With a current rating of 5 A and 50 mating cycles, it ensures durability in demanding environments, making it ideal for industrial electronics and communication systems.
ITT CANNON ZDB25S1AKN146 D Sub Connector Specifications:
- Number of contacts: 25
- Contact arrangement: size 20, socket gender
- Contact material: copper alloy
- Contact finish: gold flash (Performance Class 3)
- Shell material: steel
- Shell finish: tin
- Insulator material: glass filled thermoplastic, UL 94V-0
- Operating temperature: -55°C to +105°C
- Dielectric withstanding voltage: 1000 VAC at sea level
- Current rating: 5 A maximum
- Mating cycles: 50
- Wire gauge range: AWG 20-28
- Mounting method: plastic bracket with screwlock 4-40
- Pushfit PCB hold diameter: 3.0 mm
- Salt spray test: 12 hours
Buy the Cannon ZDB25S1AKN146 – Reliable D Sub Connector for Industrial Applications
Purchase the Cannon ZDB25S1AKN146 online today and experience dependable performance with 25 contacts, gold finish, and rugged steel shell. Perfect for industrial, electronic, and communication projects, this connector supports wire gauges from AWG 20 to AWG 28 and withstands voltages up to 1000 VAC. Its durable design includes a thermoplastic insulator rated UL 94V-0, and a mountable steel shell featuring a tin finish. Designed for multiple mating cycles and secure mounting, this connector guarantees long-lasting reliability for demanding industrial use.
Get Cannon ZDB25S1AKN146 today—built for precision, durability, and seamless integration in industrial electronics and communication systems.
Frequently Asked Questions
Where can I buy ITT CANNON ZDB25S1AKN146?
You can click on the BUY or RFQ button to purchase ZDB25S1AKN146 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part ZDB25S1AKN146?
You can download the ZDB25S1AKN146 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of ZDB25S1AKN146?
ITT CANNON
