ITT CANNON ZDE9P1AKN146 D Sub Connector
The ZDE9P1AKN146 is a low-cost, high-quality D Sub connector featuring nine pin contacts suitable for various electronic applications. This pin-type connector offers a current rating of 5 A and a dielectric withstand voltage of 1000 VAC at sea level. Its durable steel shell, tin finish, and glass-filled thermoplastic insulator ensure reliable performance in harsh environments. Designed for solder termination and mounting with a plastic bracket, it withstands operating temperatures from -55°C to +105°C, making it an ideal choice for industrial and electronic device integrations requiring dependable connectivity.
ITT CANNON ZDE9P1AKN146 D Sub Connector Specifications:
- Wire Gauge Range: AWG 20-28
- Mating Cycles: 50
- Dielectric Withstanding Voltage: 1000 VAC at sea level
- Current Rating: 5 Amax
- Contact Resistance: 20 milli Ohm max
- Operating Temperature: -55°C to +105°C
- Shell Material: Steel
- Shell Finish: Tin
- Insulator Material: Glass filled Thermoplastic, UL 94V-0
- Insulator Color: Black
- Contact Arrangement: 9 contacts, size 20
- Gender: Pin
- Contact Material: Copper alloy
- Contact Finish: Gold flash (Performance Class 3)
- Contact Termination: Right angled solder
- Mounting Method: Plastic bracket with Screwlock 4-40
- PCB Hold Diameter: 3.0 mm
Buy the Cannon ZDE9P1AKN146 – Reliable D Sub for Industrial Applications
Enhance your electronic projects with the reliable D Sub connector featuring nine gold-flash contacts rated at 5 A. Designed with a durable steel shell and thermoplastic insulator, it offers excellent performance across a temperature range from -55°C to +105°C. Perfect for industrial, automation, and communication systems, this connector supports solder termination and easy mounting with a plastic bracket and Screwlock 4-40. Trust this cost-effective yet robust connector to provide dependable, long-lasting connections in demanding environments.
Order your Cannon ZDE9P1AKN146 series connector today and ensure your electronic devices have the dependable connectivity they need for demanding environments.
Frequently Asked Questions
Where can I buy ITT CANNON ZDE9P1AKN146?
You can click on the BUY or RFQ button to purchase ZDE9P1AKN146 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part ZDE9P1AKN146?
You can download the ZDE9P1AKN146 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of ZDE9P1AKN146?
ITT CANNON
