JST (JAPAN SOLDERLESS TERMINALS) WCGH2630 Crimp Connector
The WCGH2630 is a high-quality disconnectable crimp connector designed for easy mating and secure locking, suitable for small electronics and LCD applications. It features a robust housing lock structure, contact lock mechanism for a satisfying click, and fork-shaped header contacts supported by grooves to prevent deformation. Made from phosphor bronze and tin-plated, it supports wire ranges from AWG #30 to #26, with a current rating of 1.0A and voltage rating of 50V. It meets safety standards and offers reliable performance in diverse electronic assemblies.
JST (JAPAN SOLDERLESS TERMINALS) WCGH2630 Crimp Connector Specifications:
- Current rating: 1.0A AC, DC
- Voltage rating: 50V AC, DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial/30mΩ max, After testing/50mΩ max
- Insulation resistance: 100MΩ min
- Withstanding voltage: 500V AC/minute
- Applicable wire: AWG #30 to #26, insulation OD 0.8 to 1.0mm
- Housing material: PBT, UL94V-0, natural color
- Contact material: Phosphor bronze, tin-plated
- Insertion style: Crimp
- Locking structure: Secure housing lock and contact lock
- Support for multiple circuits: 2 to 15
- Operating temperature: -25°C to +85°C
- Standards: Recognized E60389
Buy the Buy JST GH CONNECTOR Part Number WCGH2630 Online
Experience seamless online purchase of the JST WCGH2630 crimp connector, ideal for small electronics and LCD applications. Designed for easy mating with secure locking, it features a tin-plated phosphor bronze contact, supports wire ranges from AWG 30 to 26, and is rated at 1A and 50V. Its rugged housing prevents deformation, ensuring reliable connection performance. Perfect for engineers and technicians seeking durable, high-quality electrical connectors for compact device assemblies, available now for quick, hassle-free online ordering with excellent customer support.
Buy JST WCGH2630 now and experience reliable electrical connections with secure locking and corrosion resistance for small electronic projects.
Frequently Asked Questions
Where can I buy JST (JAPAN SOLDERLESS TERMINALS) WCGH2630?
You can click on the BUY or RFQ button to purchase WCGH2630 from an authorized JST (JAPAN SOLDERLESS TERMINALS) distributor.
How do I troubleshoot issues or seek technical support for part WCGH2630?
You can download the WCGH2630 datasheet or visit the JST (JAPAN SOLDERLESS TERMINALS) website for support.
Who is the manufacturer of WCGH2630?
JST (JAPAN SOLDERLESS TERMINALS)
