JST 04TJWPSVKELEDZA1 waterproof connector housing
This waterproof connector housing is designed for 4-position JWPS connectors with a 4.0mm pitch, providing IPX7 ingress protection compliant with IEC 60529. Made from glass-filled PBT and featuring silicone rubber seals, it offers high durability and reliable sealing against water ingress, suitable for industrial, outdoor, and harsh environment applications. The housing supports up to 300V and is RoHS compliant, ensuring safety and environmental standards are met. Its color-coded keying options enhance correct assembly and easy identification in complex systems.
JST 04TJWPSVKELEDZA1 waterproof connector housing Specifications:
- Material: Glass-filled PBT with silicone rubber seals
- Ingress Protection: IPX7 according to IEC 60529
- Rated Voltage: 300 V AC/DC
- Applicable Wire: AWG #22-#18, insulation O.D. 1.75-2.5 mm
- Color: Blue keying, black housing, natural keying, and blue keying options
- Temperature Range: -55°C to +85°C
- Housing Material: UL94V-0 rated, UL Recognized and CSA Certified
- Contact material: Copper alloy, tin-plated
- Standards: RoHS compliant, LR20812 certified, E60389 recognized
Buy the JST 04TJWPSVKELEDZA1 – Reliable Waterproof Connector Housing for Industrial Applications
Secure your connections with this durable waterproof connector housing designed for JWPS connectors. Featuring IPX7 ingress protection, it is ideal for outdoor, industrial, and harsh environment applications. Constructed from high-quality glass-filled PBT with silicone rubber seals, it guarantees water resistance up to 300V for reliable operation. Easy to assemble with color-coded keying options, this RoHS-compliant housing ensures safety, durability, and compliance in demanding applications. Order now online for quick and trusted delivery.
Buy JST waterproof connector housing now and ensure reliable water-resistant connections in your industrial and outdoor projects.
Frequently Asked Questions
Where can I buy JST 04TJWPSVKELEDZA1?
You can click on the BUY or RFQ button to purchase 04TJWPSVKELEDZA1 from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part 04TJWPSVKELEDZA1?
You can download the 04TJWPSVKELEDZA1 datasheet or visit the JST website for support.
Who is the manufacturer of 04TJWPSVKELEDZA1?
JST
