JST 08FM10STLFSN FFC Connector
This is an 8-position FFC connector with a 1.0mm pitch, designed for side entry installation and through-hole mounting. It features phosphor bronze contacts with resilient spring members to ensure stable connectivity under vibration and impact. Made with UL94V-0 rated housing materials like PBT for through-hole and PPS for SMT versions, it supports 50V operation, has a temperature range of -25°C to +85°C, and is RoHS compliant. Suitable for high-density electronic applications requiring reliable, compact connections for flexible flat cables.
JST 08FM10STLFSN FFC Connector Specifications:
- Contact Material: Phosphor bronze, copper-undercoated, in-plated (reflow treatment)
- Housing Material: PBT, UL94V-0
- Current Rating: 0.5A AC, DC
- Voltage Rating: 50V AC, DC
- Temperature Range: -25°C to +85°C
- Contact Resistance: Initial value/20mΩ max., after environmental testing/30mΩ
- Insulation Resistance: 800MΩ min.
- Withstanding Voltage: 500V AC/minute
- Applicable FFC/FPC: 1.0mm pitch, conductor width 0.7mm, conductor thickness 0.33mm
- Applicable PC Board Thickness: 0.8 to 1.6mm
- Connector Type: Side entry through-hole
- RoHS Compliance: Yes
- Standards: Recognized UL, Certified LR20812
Buy the Cooper Series FM: 8-Position 1.0mm Pitch FFC Connector: 08FM10STLFSN
Enhance your electronic devices with the Cooper FM 08FM10STLFSN FFC connector, featuring a compact 1.0mm pitch, side entry design, and reliable through-hole mounting. Its robust phosphor bronze contacts and UL94V-0 rated housing ensure long-lasting performance even under vibration and impact. Supporting 50V operation and a temperature range of -25°C to +85°C, this RoHS-compliant connector is perfect for space-constrained, high-density applications needing secure, flexible flat cable connections. Order now for quick online delivery.
Buy Cooper FM 08FM10STLFSN now and experience reliable, space-saving connections for high-density electronic assemblies.
Frequently Asked Questions
Where can I buy JST 08FM10STLFSN?
You can click on the BUY or RFQ button to purchase 08FM10STLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part 08FM10STLFSN?
You can download the 08FM10STLFSN datasheet or visit the JST website for support.
Who is the manufacturer of 08FM10STLFSN?
JST
