JST 2PSZN Connector Housing
This low-profile connector housing from the SZN series offers a compact and reliable solution for PCB applications with a 1.50mm pitch. Designed for easy through-hole mounting and crimp termination, it accommodates wire sizes from AWG 30 to 26, making it suitable for space-constrained modules. Constructed from UL94V-0 rated PA 66 in natural color, it provides durability and RoHS compliance. The connector features robust construction, housing lances for secure contact insertion, and is ideal for low-current, space-efficient circuit connections in industrial and electronic devices.
JST 2PSZN Connector Housing Specifications:
- Pitch: 1.50mm
- Number of circuits: 2 to 13
- Wire range: AWG 30 to 26
- Insulation diameter: 0.05~0.13mm
- Material: PA 66, UL94V-0, natural color
- Contact resistance: Not specified
- Voltage rating: 50V AC/DC
- Current rating: 0.7A AC/DC (AWG 26)
- Temperature range: -25°C to +85°C
- Insulation resistance: 500MΩ min.
- Withstanding voltage: 500V AC/minute
- Applicable PCB thickness: 0.6 to 1.2mm
- RoHS compliant
Buy the JST SZN Connector – Reliable PCB Mounting for Industrial Applications
Discover the high-quality JST SZN connector housing designed for reliable PCB applications. With a 1.50mm pitch, supports AWG 30-26 wires, and features easy through-hole mounting, this connector ensures secure and efficient circuit connections. Made from UL94V-0-rated PA 66 in natural color, it offers excellent durability, RoHS compliance, and optimal insulating properties. Perfect for industrial automation, electronics, and space-constrained devices, this connector provides a dependable and compliant solution for your manufacturing needs. Order online today to streamline your assembly process and ensure long-term performance.
Buy JST SZN connector housing now and enjoy secure, space-saving connections with durable, RoHS-compliant materials perfect for industrial circuit designs.
Frequently Asked Questions
Where can I buy JST 2PSZN?
You can click on the BUY or RFQ button to purchase 2PSZN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part 2PSZN?
You can download the 2PSZN datasheet or visit the JST website for support.
Who is the manufacturer of 2PSZN?
JST
