JST B24BPADSS1FLFSN connector header
A 24-position through-hole connector header with a 2.0mm pitch, designed for reliable pin alignment and secure electrical connections in diverse electronic assemblies. The connector features robust construction, RoHS compliance, and a stable connection mechanism suitable for high-density mounting and various PCB thicknesses. Its material is copper alloy, tin-plated for durability, and it meets UL and RoHS standards. Ideal for applications requiring dependable and precise terminal connections with easy installation and maintenance.
JST B24BPADSS1FLFSN connector header Specifications:
- Pitch: 2.0mm
- Number of positions: 24
- Material: Copper alloy, tin-plated (reflow treatment)
- Rated current: 3A AC/DC (AWG #22 wire)
- Voltage rating: 250V AC/DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial/10m, post-environment testing/20m max
- Insulation resistance: ≥1,000MΩ
- Withstanding voltage: 800V AC/minute
- Applicable wire: AWG #28 to #22
- Applicable PCB thickness: 1.6mm
- RoHS compliant
- Standards: Recognized E60389, Certified LR20812
Buy the Buy JST Connector Header Part Number B24BPADSS1FLFSN Online
Purchase the JST connector header B24BPADSS1FLFSN online today for high-density, reliable pin connections in electronic assemblies. This connector offers durable construction, RoHS compliance, and precise fitment suitable for various PCB thicknesses. Its 2.0mm pitch and 24 positions make it ideal for space-saving designs and complex circuitry while ensuring robust electrical performance. Easy to install and maintain, this high-quality connector guarantees secure contacts and stable operation across diverse applications, enhancing your electronic system’s reliability and longevity.
Order your JST Connector Header B24BPADSS1FLFSN today and ensure reliable, high-density connections for your electronic projects with durable, RoHS compliant hardware.
Frequently Asked Questions
Where can I buy JST B24BPADSS1FLFSN?
You can click on the BUY or RFQ button to purchase B24BPADSS1FLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part B24BPADSS1FLFSN?
You can download the B24BPADSS1FLFSN datasheet or visit the JST website for support.
Who is the manufacturer of B24BPADSS1FLFSN?
JST
