JST B2BPHKLFSN Connector Header
This is a high-quality top-entry connector header from the PH series, featuring 2 positions with a 2.00mm pitch. Designed for through-hole mounting, it supports press-fit and solder termination methods. The connector comes in an ivory color, suitable for various electronic assembly applications. It is made of durable copper alloy and water-resistant PA 66, UL94V-0, with tin-plated contacts for reliable electrical connection. The contact resistance is low, and it complies with RoHS standards, making it ideal for high-density, low-cost electronic devices requiring secure and stable connections.
JST B2BPHKLFSN Connector Header Specifications:
- Pitch: 2.00mm
- Material: Copper alloy, tin-plated
- Color: Ivory (natural white)
- Contact resistance: Low, initial / 10m typical, after environmental testing / 20m maximum
- Voltage rating: 100V AC/DC
- Current rating: 2A AC/DC (per contact for AWG #24 wire)
- Temperature range: -25°C to +85°C
- Insulation resistance: 1,000M ohms minimum
- Withstanding voltage: 800V AC/minute
- Applicable wire: AWG #32 to #24
- Board thickness: 0.8 to 1.6mm
- RoHS compliant
- Mounting: Through-hole, top-entry
- Contact finish: Tin-plated
- Environmental standard: RoHS
- Certifications: Recognized E60389, LR20812, R75087
Buy the Buy JST PH Connector Part Number B2BPHKLFSN Online
Order the JST PH Connector Header B2BPHKLFSN online today and ensure secure, reliable connections in your electronics projects. Crafted from durable copper alloy and water-resistant PA 66, this high-quality, RoHS-compliant top-entry connector supports through-hole mounting with press-fit and solder options. It features a precise 2.00mm pitch, low contact resistance, and high current capacity of 2A. Perfect for dense electronic configurations, it offers stable mechanical and electrical performance, making it the ideal choice for various industrial, automation, and consumer electronics applications.
Buy JST PH connector part number B2BPHKLFSN now and experience unmatched reliability and performance for your electronic assemblies.
Frequently Asked Questions
Where can I buy JST B2BPHKLFSN?
You can click on the BUY or RFQ button to purchase B2BPHKLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part B2BPHKLFSN?
You can download the B2BPHKLFSN datasheet or visit the JST website for support.
Who is the manufacturer of B2BPHKLFSN?
JST
